Lenze E84AVHC Series - C00840 | 16 Bit-SysInput analog

8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00840
738 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
C00840
C00839/40 L_PhaseDiff_2
: dnSet_p
C00839/41 L_PhaseDiff_1
: dnAdd_p
C00839/42 L_PhaseDiff_2
: dnAdd_p
C00839/43 L_MckStateInterface_1
: dnPosIn_p
C00839/44 L_Odometer_1
: dnInPosition_p
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00839 | 32bit input AdditionalFBsHL
Data type: INTEGER_32
Index: 23736
d
= 5CB8
h
Parameter | Name:
C00840 | 16Bit-SysInput analog
Data type: INTEGER_16
Index: 23735
d
= 5CB7
h
Display in percent of 16-bit input values of different I/O level blocks
Display range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Info
C00840/1 LS_AnalogOutput
: nOut1_a (V)
C00840/2 LP_CanOut1
: wState
C00840/3 LP_CanOut1
: wOut2
C00840/4 LP_CanOut1
: wOut3
C00840/5 LP_CanOut1
: wOut4
C00840/6 LP_CanOut2
: wOut1
C00840/7 LP_CanOut2
: wOut2
C00840/8 LP_CanOut2
: wOut3
C00840/9 LP_CanOut2
: wOut4
C00840/10 LP_CanOut3
: wOut1
C00840/11 LP_CanOut3
: wOut2
C00840/12 LP_CanOut3
: wOut3
C00840/13 LP_CanOut3
: wOut4
C00840/14 LS_DisFree_a
:nDis1_a
C00840/15 LS_DisFree_a:nDis2_a
C00840/16 LS_DisFree_a
:nDis3_a
C00840/17 LS_DisFree_a
:nDis4_a
C00840/18 LS_DisFree:wDis1
C00840/19 LS_DisFree
:wDis2
C00840/20 LS_DisFree
:wDis3
C00840/21 LS_DisFree
:wDis4
C00840/22 LP_MciOut
: wState
C00840/23 LP_MciOut
:wOut2
C00840/24 LP_MciOut
:wOut3
C00840/25 LP_MciOut
: wOut4
C00840/26 LP_MciOut
: wOut5
C00840/27 LP_MciOut: wOut6
C00840/28 LP_MciOut
: wOut7
C00840/29 LP_MciOut
: wOut8
C00840/30 LP_MciOut
: wOut9
C00840/31 LP_MciOut
: wOut10
