Lenze E84AVHC Series User Manual

8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00448
660 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
C00448
C00455
C00456
C00458
Parameter | Name:
C00448 | DigOut: Decoupling value
Data type: UNSIGNED_16
Index: 24127
d
= 5E3F
h
As of version 04.00.00
Definition of the value the digital output terminals are to have in the decoupled state.
• Bit set = HIGH level
Configuring exception handling of the output terminals
Setting range (min. hex value | max. hex value) Lenze setting
0x0000 0xFFFF 0x0000 (decimal: 0)
Value is bit-coded: (; =bit set)
Bit 0  Relay_ON
Bit 1  DigOut1_ON
Bit 2  DigOut2_ON
Bit 3  DigOut3_ON
Bit 4  DigOut4_ON
Bit 5  HighCurrent_ON
Bit 6  Reserved
Bit 7  Reserved
Bit 8  Reserved
Bit 9  Reserved
Bit 10  Reserved
Bit 11  Reserved
Bit 12  Reserved
Bit 13  Reserved
Bit 14  Reserved
Bit 15  Reserved
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT
Parameter | Name:
C00455 | FB_call table
Data type: UNSIGNED_16
Index: 24120
d
= 5E38
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00456 | Editor level
Data type: UNSIGNED_8
Index: 24119
d
= 5E37
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00458 | SYS_call table
Data type: UNSIGNED_16
Index: 24117
d
= 5E35
h
This code is for device-internal use only and must not be written to by the user!
