Firmware 05.00 - DMS 4.2 EN - 02/2010 L 591
8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00010
C00010
C00011
C00012
3020 SwitchPos|Keypad Application: Switch-off positioning
I/O level: "Keypad" control mode
3021 SwitchPos|PC Application: Switch-off positioning
I/O level: "PC" control mode
3030 SwitchPos|CAN Application: Switch-off positioning
I/O level: "CAN" control mode
3040 SwitchPos|MCI Application: Switch-off positioning
I/O level: "MCI" control mode
; Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C00008 | Original application|Control source
Data type: UNSIGNED_16
Index: 24567
d
= 5FF7
h
Parameter | Name:
C00010 | AIN1: Characteristic
Data type: INTEGER_16
Index: 24565
d
= 5FF5
h
As of version 04.00.00
Analog terminals
: Signal adaptation via characteristic
Setting range (min. value | unit | max. value)
0.00 % 199.99
Subcodes Lenze setting Info
C00010/1 0.00 % AIN1: (+y0) = min
C00010/2 0.00 % AIN1: (+x0) = Dead band
C00010/3 0.00 % AIN1: (-y0) = (-min)
C00010/4 0.00 % AIN1: (-x0) = (-Dead band)
C00010/5 100.00 % AIN1: (+ymax)
C00010/6 100.00 % AIN1: (+xmax)
C00010/7 100.00 % AIN1: (-ymax)
C00010/8 100.00 % AIN1: (-xmax)
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C00011 | Appl.: Reference speed
Data type: UNSIGNED_16
Index: 24564
d
= 5FF4
h
Setting the reference speed
In the controller, all speed-related signals are processed to one reference variable in percent.
Set a reference speed here that corresponds to 100 %.
Note:
This is not a maximum limitation!
All values in percent in the controller may be in the range of 0 ... 199.99 %.
Setting range (min. value | unit | max. value) Lenze setting
50 rpm 60000 1500 rpm
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C00012 | Accel. time - main setpoint
Data type: UNSIGNED_32
Index: 24563
d
= 5FF3
h
FB L_NSet_1: Acceleration time of the ramp generator for the main speed setpoint
This ramp generator is basically used for all speed-controlled technology applications.
Setting range (min. value | unit | max. value) Lenze setting
0.000 s 999.999 2.000 s
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1000
