Lenze E84AVHC Series User Manual

8400 HighLine | Parameter setting & configuration
Basic drive functions (MCK)
Holding brake control
440 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
Short overview of parameters for holding brake control:
8.12.2.1 Operating mode
For different applications and tasks, different operating modes are available under
C02580
. The selected operating mode determines whether the holding brake control is
used and how the holding brake will be switched.
Mode 0: Brake control off
In this mode, brake control is switched off (not active).
 The trigger signal bBrkReleaseOut for the holding brake control switching element is set
to FALSE.
 The status signal bBrkReleased is set to FALSE.
Parameter Info Lenze setting
Value Unit
C02580 Holding brake: Operating mode 0: Brake control off
C02581/1
Holding brake: Switching threshold 5.00 %
C02581/2
Holding brake: hysteresis for releasing 1.00 %
C02581/3
Holding brake: hysteresis for applying 1.00 %
C02582
Holding brake: Setting 0
C02589/1
Holding brake: applying time 100 ms
C02589/2
Holding brake: Release time 100 ms
C02589/3
In preparation - without function at the moment!
Holding brake: Waiting time status
100 ms
C02593/1
Holding brake: Actual value monitoring 0.000 ms
C02593/2
Holding brake: Application delay 0.000 ms
C02610/1
MCK: Holding brake ramp time synchr. 2.000 s
C02607 Holding brake: Status -
C00830/68 MCK: nBrkTorqueAdd_a - %
C00833/80 MCK: bBrkRelease -
Highlighted in grey = display parameter
 Note!
In the Lenze setting, the mode 0 is preset to get into a safe state after the mains
is switched on.
