Lenze E84AVHC Series User Manual

8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00480
664 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
C00480
C00481
C00482
C00483
Parameter | Name:
C00480 | LS_DisFree_b
Data type: UNSIGNED_16
Index: 24095
d
= 5E1F
h
SB LS_DisFree_b: Display of the input values
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded: Info
Bit 0 bDis1 Signal level input bDis1 ... bDis16
... ...
Bit 15 bDis16
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT
Parameter | Name:
C00481 | LS_DisFree
Data type: UNSIGNED_16
Index: 24094
d
= 5E1E
h
SB LS_DisFree: Display of the input values
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded:
Bit 0 Active
... ...
Bit 15 Active
Subcodes Info
C00481/1 Input values wDis1 ... wDis8
C00481/...
C00481/8
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT
Parameter | Name:
C00482 | LS_DisFree_a
Data type: INTEGER_16
Index: 24093
d
= 5E1D
h
SB LS_DisFree_a: Display of the input values
Display range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Info
C00482/1 Input values nDis1_a ... nDis8_a
C00482/...
C00482/8
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00483 | LS_DisFree_p
Data type: INTEGER_32
Index: 24092
d
= 5E1C
h
SB LS_DisFree_p: Display of the input values
Display range (min. value | unit | max. value)
-2147483647 incr 2147483647
Subcodes Info
C00483/1 Input values dnDis1_p ... dnDis8_p
C00483/...
C00483/8
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT Scaling factor: 1
