8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00634
C00634
C00635
C00636
C00637
Parameter | Name:
C00634 | L_NSet_1: wState
Data type: UNSIGNED_16
Index: 23941
d
= 5D85
h
FB L_NSet_1: Bit-coded status display
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded: Info
Bit 0 No blocking zone active "1" ≡ No blocking zone set for constant speeds
Bit 1 Blocking zone 1 active "1" ≡ Suppression of constant speed characteristics
within the limits of blocking zone 1
Bit 2 Blocking zone 2 active "1" ≡ Suppression of constant speed characteristics
within the limits of blocking zone 2
Bit 3 Blocking zone 3 active "1" ≡ Suppression of constant speed characteristics
within the limits of blocking zone 3
Bit 4 Jog in blocking zone "1" ≡ A ramp is used to keep the speed setpoint within a
speed blocking zone
Bit 5 MaxLimit active "1" ≡ Speed setpoint is at the maximum speed limit
Bit 6 MinLimit active "1" ≡ Speed setpoint is at the minimum speed limit
Bit 7 Reserved
Bit 8 Reserved
Bit 9 Reserved
Bit 10 Reserved
Bit 11 Reserved
Bit 12 Reserved
Bit 13 Reserved
Bit 14 Reserved
Bit 15 Reserved
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT
Parameter | Name:
C00635 | L_NSet_1: nMaxLimit
Data type: INTEGER_16
Index: 23940
d
= 5D84
h
FB L_NSet_1: Maximum speed setpoint for speed setpoint limitation
Setting range (min. value | unit | max. value) Lenze setting
-199.99 % 199.99 199.99 %
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00636 | L_NSet_1: nMinLimit
Data type: INTEGER_16
Index: 23939
d
= 5D83
h
FB L_NSet_1: Minimum speed setpoint for speed setpoint limitation
Setting range (min. value | unit | max. value) Lenze setting
-199.99 % 199.99 -199.99 %
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00637 | L_NSet_1: Blocking zone output
Data type: INTEGER_16
Index: 23938
d
= 5D82
h
FB L_NSet_1: Display of the speed setpoint after blocking zone function processing
Display range (min. value | unit | max. value)
-199.99 % 199.99
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT Scaling factor: 100
