Lenze E84AVHC Series - C02582 | Holding brake: Setting

8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C02582
790 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
C02582
Parameter | Name:
C02582 | Holding brake: Setting
Data type: UNSIGNED_8
Index: 21993
d
= 55E9
h
Activation of functional holding brake control options
Holding brake control
Setting range (min. hex value | max. hex value) Lenze setting
0x00 0xFF 0x00 (decimal: 0)
Value is bit-coded: (; =bit set) Info
Bit 0  Control inverted Activation of inverted control
•"1" ≡ Inverted logic of trigger signal for holding brake
control switching element
Bit 1  nAct < nMin at CInh Brake response in case of pulse inhibit
•"1" ≡ With pulse inhibit, the actual speed value is
monitored. The holding brake is applied when the
actual speed reaches the "Application" threshold
value.
• Note: This function is used to avoid the wear of the
holding brake of a drive with horizontal travel path
when the controller is inhibited and rotation occurs.
Bit 2  Inverted feedforward control Precontrol inversion
•"1" ≡ The direction of the precontrol value before
setting the release signal of the holding brake is
inverted.
Bit 3  Horizontal/winding technology Direction of the axis
•"1" ≡ The direction of the axis is horizontal or rotary.
The gravitational acceleration does not cause any
movement.
•"0" ≡ The direction of the axis is vertical. The
gravitational acceleration does not cause any
movement.
Bit 4  Reserved
Bit 5  Reserved
Bit 6  Reserved
Bit 7  Reserved
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT
