8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C01218
770 L Firmware 05.00 - DMS 4.2 EN - 02/2010
C01218
C01219
Parameter | Name:
C01218 | MCK: PosFollower setting
Data type: UNSIGNED_8
Index: 23357
d
= 5B3D
h
Settings for "Position follower" mode
Position follower
Setting range (min. hex value | max. hex value) Lenze setting
0x00 0xFF 0x0C (decimal: 12)
Value is bit-coded: (; =bit set) Info
Bit 0 Speed feedf. control:
nSpeedSetValue_a
"1" speed feedforward control value comes from main
setpoint nSpeedSetValue_a
Bit 1 Speed feedf. control:
nSpeedAddValue_v
"1" speed feedforward control value comes from
additive speed value nSpeedAddValue_v
Bit 2 ; HW limit switch on "1" travel range monitoring by means of hardware limit
switches is active. The error response can be
parameterised in C00595/1
and C00595/2.
Bit 3 ; SW limit switch on "1" travel range monitoring by means of parameterised
software limit positions is active. The error response can
be parameterised in C00595/3
and C00595/4.
Bit 4 Reserved
Bit 5 Reserved
Bit 6 Reserved
Bit 7 Reserved
; Read access ; Write access CINH PLC STOP No transfer COM MOT
Parameter | Name:
C01219 | MCK: Speed follower setting
Data type: UNSIGNED_8
Index: 23356
d
= 5B3C
h
Settings for "Speed follower" mode
Speed follower
Setting range (min. hex value | max. hex value) Lenze setting
0x00 0xFF 0x0C (decimal: 12)
Value is bit-coded: (; =bit set) Info
Bit 0 Reserved
Bit 1 Reserved
Bit 2 ; HW limit switch on "1" travel range monitoring by means of hardware limit
switches is active. The error response can be
parameterised in C00595/1
and C00595/2.
Bit 3 ; SW limit switch on "1" travel range monitoring by means of parameterised
software limit positions is active. The error response can
be parameterised in C00595/3
and C00595/4.
Bit 4 Reserved
Bit 5 Reserved
Bit 6 Reserved
Bit 7 Position controller off
; Read access ; Write access CINH PLC STOP No transfer COM MOT
