8400 HighLine | Parameter setting & configuration
Working with the FB Editor
Reconfiguring the predefined interconnection
13.4 Reconfiguring the predefined interconnection
How to proceed:
1. Insert additionally required objects into the interconnection.
2. Hide unneeded inputs/outputs of function blocks and system blocks to obtain a clearly
arranged interconnection.
3. Arrange the objects in the drawing area in a reasonable manner.
4. Establish the connections required for the desired function.
5. If required, change (optimise) the processing order of the function blocks.
Tip!
Detailed information on the individual steps can be obtained from the following
subchapters!
13.4.1 Inserting/Deleting objects
Objects can be inserted in the interconnection via the FB Editor toolbar and the context
menu of the drawing area. The following subchapters provide detailed information on how
to insert/delete the different objects.
Tip!
Use the context menu of the drawing area to insert a function block, system block,
port block or comment directly to the current position of the mouse pointer in the
drawing area.
If you insert an object via the corresponding icon in the FB Editor toolbar, the object
is always placed at the top left corner in the drawing area.
Interconnection elements cannot only be copied within the same interconnection
but also across all devices within the same project, as long as the devices stem from
the same product family. Copying interconnection elements (across all devices)
( 861)
Note!
With the "StateLine" version, the interconnection shown in the application level
cannot be edited.
Symbol Function
Inserting a function block
( 842)
Inserting a system block ( 844)
Inserting a port block
( 846)
Inserting a comment
( 848)
