8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00070
600 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
C00070
C00071
C00072
C00073
Parameter | Name:
C00070 | Vp speed controller
Data type: UNSIGNED_16
Index: 24505
d
= 5FB9
h
Gain factor Vp of the speed controller for different operating modes
Setting range (min. value | unit | max. value)
0.00 600.00
Subcodes Lenze setting Info
C00070/1 15.00 SLVC: Vp speed controller
C00070/2 6.00 SC: Vp speed controller
; Read access ; Write access CINH PLC STOP No transfer COM ; MOT Scaling factor: 100
Parameter | Name:
C00071 | Ti speed controller
Data type: UNSIGNED_16
Index: 24504
d
= 5FB8
h
Reset time Ti of the speed controller for different operating modes
Setting range (min. value | unit | max. value)
0.0 ms 6000.0
Subcodes Lenze setting Info
C00071/1 100.0 ms SLVC: Ti speed controller
C00071/2 50.0 ms SC: Ti speed controller
; Read access ; Write access CINH PLC STOP No transfer COM ; MOT Scaling factor: 10
Parameter | Name:
C00072 | SC: Tdn speed controller
Data type: UNSIGNED_16
Index: 24503
d
= 5FB7
h
Differential time constant Tdn of the speed controller for SC (servo control) mode
Setting range (min. value | unit | max. value) Lenze setting
0.00 ms 3.00 0.00 ms
; Read access ; Write access CINH PLC STOP No transfer COM ; MOT Scaling factor: 100
Parameter | Name:
C00073 | Imax/M controller gain
Data type: UNSIGNED_16
Index: 24502
d
= 5FB6
h
Gain factor Vp of certain controllers for different operating modes
Setting range (min. value | unit | max. value)
0.00 16.00
Subcodes Lenze setting Info
C00073/1 0.25 VFC: Vp Imax controller
• After the motor to be used has been selected from the
motor catalogue, the suitable value can be entered
automatically.
C00073/2 1.25 SLVC: Vp torque controller
; Read access ; Write access CINH PLC STOP No transfer COM ; MOT Scaling factor: 100
