Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010 L 23
8400 HighLine | Parameter setting & configuration
About this documentation
Terminology used
1.3 Terminology used
Term Meaning
»Engineer« Lenze PC software which supports you in "engineering" (parameterisation,
diagnostics and configuration) throughout the whole life cycle, i.e. from
planning to maintenance of the commissioned machine.
Application block Block for a technology application (e.g. actuating drive speed)
A technology application is a drive solution based on the experience and know-
how of Lenze in which function blocks interconnected to a signal flow form the
basis for implementing typical drive tasks.
ASM Asynchronous motor
Service brake The service brake serves to shutdown rotary or translatory masses in motion in
a controlled manner. The energy to be dissipated in this process is produced in
the form of friction energy. Unlike emergency braking, this process is a regular
and recurring operating mode.
Code Parameter used for controller parameterisation or monitoring.
The term is usually called "index".
Display code Parameter that displays the current state or value of an input/output of a
system block.
FB Editor Function block editor
Graphical interconnection tool which is provided for FB interconnections in the
»Engineer« on the FB Editor tab and by means of which the applications
integrated in the 8400 HighLine controller can also be reconfigured and
extended by individual functions.
Function block General designation of a function block for free interconnection (only HighLine).
A function block can be compared with an integrated circuit that contains a
certain control logic and delivers one or several values when being executed.
• Each function block has a unique identifier (the instance name) and a
processing number which defines the position at which the function block is
calculated during the task cycle.
Representation e.g. "L_Arithmetik1": Function block for arithmetic operations
Holding brake The holding brake serves to statically hold e.g. a position during the downtimes
of a robot/travelling/synchronous/hoist drive.
Keypad The keypad is an alternative to the PC for the local operation, parameterisation,
and diagnostics in a simple manner.
• Detailed type designation: X400 keypad
• Order designation: EZAEBK1001
LA Abbreviation: Lenze Application block, e.g. LA_NCtrl, block for the "Actuating
drive speed" application
Lenze setting This setting is the default factory setting of the device.
LP Abbreviation: Lenze Port block, e.g. LP_CanIn1, port block CAN1
LS Abbreviation: Lenze System block, e.g. LS_DigitalInput, system block for digital
input signals
Emergency brake The emergency brake serves to shutdown rotary or translatory masses in motion
in emergency situations. Emergency situations are exceptional situations that
only occur sporadically.
Port block Block for implementing the process data transfer via a fieldbus
QSP Quick stop
SC Operating mode: Servo Control
SLVC Operating mode: Sensorless vector control ("SensorLess Vector Control")
Subcode If a code contains several parameters, the individual parameters are stored
under "subcodes".
This Manual uses a slash "/" as a separator between code and subcode
(e.g. "C00118/3").
The term is usually called "subindex".
