8400 HighLine | Parameter setting & configuration
Function library
Function blocks | L_PhaseIntK_1
1030 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
14.1.115.3 Calculation of the output signal
The output value at dnOut_p can be detected according to the following formula:
Example
You want to determine the counter content of the integrator at a certain speed at the input
and a certain integration time t.
Given values:
nIn_v = 1000 rpm ≈ integer value 1092
Integration time t = 10 s
Starting value of the integrator = 0
Solution:
Conversion of the input signal at nIn_v:
Calculation of the output value:
t = integration time
16384 ≡ 15000 rpm
1 ≡ 1 incr.
dnOut_p [incr.] nIn_v [rpm] t [s] 65535 [incr./rev.]⋅⋅=
1000 rpm
1000 rev.
60 s
-----------------------=
dnOut_p
1000 rev.
60 s
-----------------------
10 s
65535 incr.
rev.
----------------------------
⋅⋅ 10922666 incr.==
