Lenze E84AVHC Series User Manual

8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00825
710 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
C00825
Parameter | Name:
C00825 | L_DigitalLogic5_1: Truth table
Data type: UNSIGNED_8
Index: 23750
d
= 5CC6
h
FB L_DigitalLogic5_1: Parameterisation of the truth table
Selection list
0False
1True
Subcodes Lenze setting Info
C00825/1 0: FALSE bOut for bIn1=0 / bIn2=0 / bIn3=0 / bIn4=0 / bIn5=0
C00825/2 0: FALSE bOut for bIn1=1 / bIn2=0 / bIn3=0 / bIn4=0 / bIn5=0
C00825/3 0: FALSE bOut for bIn1=0 / bIn2=1 / bIn3=0 / bIn4=0 / bIn5=0
C00825/4 0: FALSE bOut for bIn1=1 / bIn2=1 / bIn3=0 / bIn4=0 / bIn5=0
C00825/5 0: FALSE bOut for bIn1=0 / bIn2=0 / bIn3=1 / bIn4=0 / bIn5=0
C00825/6 0: FALSE bOut for bIn1=1 / bIn2=0 / bIn3=1 / bIn4=0 / bIn5=0
C00825/7 0: FALSE bOut for bIn1=0 / bIn2=1 / bIn3=1 / bIn4=0 / bIn5=0
C00825/8 0: FALSE bOut for bIn1=1 / bIn2=1 / bIn3=1 / bIn4=0 / bIn5=0
C00825/9 0: FALSE bOut for bIn1=0 / bIn2=0 / bIn3=0 / bIn4=1 / bIn5=0
C00825/10 0: FALSE bOut for bIn1=1 / bIn2=0 / bIn3=0 / bIn4=1 / bIn5=0
C00825/11 0: FALSE bOut for bIn1=0 / bIn2=1 / bIn3=0 / bIn4=1 / bIn5=0
C00825/12 0: FALSE bOut for bIn1=1 / bIn2=1 / bIn3=0 / bIn4=1 / bIn5=0
C00825/13 0: FALSE bOut for bIn1=0 / bIn2=0 / bIn3=1 / bIn4=1 / bIn5=0
C00825/14 0: FALSE bOut for bIn1=1 / bIn2=0 / bIn3=1 / bIn4=1 / bIn5=0
C00825/15 0: FALSE bOut for bIn1=0 / bIn2=1 / bIn3=1 / bIn4=1 / bIn5=0
C00825/16 0: FALSE bOut for bIn1=1 / bIn2=1 / bIn3=1 / bIn4=1 / bIn5=0
C00825/17 0: FALSE bOut for bIn1=0 / bIn2=0 / bIn3=0 / bIn4=0 / bIn5=1
C00825/18 0: FALSE bOut for bIn1=1 / bIn2=0 / bIn3=0 / bIn4=0 / bIn5=1
C00825/19 0: FALSE bOut for bIn1=0 / bIn2=1 / bIn3=0 / bIn4=0 / bIn5=1
C00825/20 0: FALSE bOut for bIn1=1 / bIn2=1 / bIn3=0 / bIn4=0 / bIn5=1
C00825/21 0: FALSE bOut for bIn1=0 / bIn2=0 / bIn3=1 / bIn4=0 / bIn5=1
C00825/22 0: FALSE bOut for bIn1=1 / bIn2=0 / bIn3=1 / bIn4=0 / bIn5=1
C00825/23 0: FALSE bOut for bIn1=0 / bIn2=1 / bIn3=1 / bIn4=0 / bIn5=1
C00825/24 0: FALSE bOut for bIn1=1 / bIn2=1 / bIn3=1 / bIn4=0 / bIn5=1
C00825/25 0: FALSE bOut for bIn1=0 / bIn2=0 / bIn3=0 / bIn4=1 / bIn5=1
C00825/26 0: FALSE bOut for bIn1=1 / bIn2=0 / bIn3=0 / bIn4=1 / bIn5=1
C00825/27 0: FALSE bOut for bIn1=0 / bIn2=1 / bIn3=0 / bIn4=1 / bIn5=1
C00825/28 0: FALSE bOut for bIn1=1 / bIn2=1 / bIn3=0 / bIn4=1 / bIn5=1
C00825/29 0: FALSE bOut for bIn1=0 / bIn2=0 / bIn3=1 / bIn4=1 / bIn5=1
C00825/30 0: FALSE bOut for bIn1=1 / bIn2=0 / bIn3=1 / bIn4=1 / bIn5=1
C00825/31 0: FALSE bOut for bIn1=0 / bIn2=1 / bIn3=1 / bIn4=1 / bIn5=1
C00825/32 0: FALSE bOut for bIn1=1 / bIn2=1 / bIn3=1 / bIn4=1 / bIn5=1
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
