Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010 L 105
8400 HighLine | Parameter setting & configuration
Motor control (MCTRL)
Selecting the operating mode
5.2 Selecting the operating mode
The operating mode for the motor control is selected in C00006
. The default setting is V/f
characteristic control (VFCplus) with a linear characteristic.
The following operating modes can be selected for the 8400 HighLine C controller in
C00006
:
V/f characteristic control (VFCplus)
The V/f characteristic control (VFCplus) is an operating mode for standard frequency
inverter applications based on a simple and robust control process which is suitable for the
operation of machines with linear or square-law load torque characteristic (e.g. fans).
Furthermore, this operating mode is also suitable for group drives and special motors. Due
to the low parameterisation effort, commissioning of such applications is fast and easy.
The Vmin boost (C00016
) and slip compensation (C00021) required for optimising the
drive behaviour are dimensioned for machines with power adaptation to the inverter in
the Lenze setting.
V/f control (VFCplus + encoder)
V/f control can be selected if operation with speed feedback is required. This operating
mode includes an additional parameterisable slip regulator which dynamically adapts the
actual speed value to the speed setpoint.
Operating mode Speed feedback
6 V/f characteristic control (VFCplus)
with a linear characteristic
8 V/f characteristic control (VFCplus)
with a quadratic characteristic
10 V/f characteristic control (VFCplus)
with a user-definable characteristic
(from version 04.00.00)
7 V/f control (VFCplus + encoder)
with a linear characteristic z
9 V/f control (VFCplus + encoder)
with a quadratic characteristic z
4 Sensorless vector control (SLVC)
2 Servo control (SC) z
