8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00074
C00074
C00075
C00076
C00077
C00078
Parameter | Name:
C00074 | Imax/M controller reset time
Data type: UNSIGNED_16
Index: 24501
d
= 5FB5
h
Reset time Ti of certain controllers for different operating modes
Setting range (min. value | unit | max. value)
0 ms 9990
Subcodes Lenze setting Info
C00074/1 65 ms VFC: Ti Imax controller
C00074/2 30 ms SLVC: Ti torque controller
; Read access ; Write access  CINH  PLC STOP  No transfer  COM ; MOT Scaling factor: 1
Parameter | Name:
C00075 | Vp current controller
Data type: UNSIGNED_16
Index: 24500
d
= 5FB4
h
Gain factor Vp of the current controller for SC (servo control) mode and certain inverter functions (parameter
identification, flying restart circuit)
• After the motor to be used has been selected from the motor catalogue, the suitable value can be entered
automatically.
Setting range (min. value | unit | max. value) Lenze setting
0.00 V/A 500.00 7.00 V/A
; Read access ; Write access  CINH  PLC STOP  No transfer  COM ; MOT Scaling factor: 100
Parameter | Name:
C00076 | Ti current controller
Data type: UNSIGNED_16
Index: 24499
d
= 5FB3
h
Reset time Ti of the current controller for SC (servo control) mode and certain inverter functions (parameter
identification, flying restart circuit)
• After the motor to be used has been selected from the motor catalogue, the suitable value can be entered
automatically.
Setting range (min. value | unit | max. value) Lenze setting
0.00 ms 500.00 10.61 ms
; Read access ; Write access  CINH  PLC STOP  No transfer  COM ; MOT Scaling factor: 100
Parameter | Name:
C00077 | SC: Vp field controller
Data type: UNSIGNED_16
Index: 24498
d
= 5FB2
h
Gain factor Vp of the field controller for SC (servo control) mode
• After the motor to be used has been selected from the motor catalogue, the suitable value can be entered
automatically.
Setting range (min. value | unit | max. value) Lenze setting
0.00 500.00 12.80
; Read access ; Write access  CINH  PLC STOP  No transfer  COM ; MOT Scaling factor: 100
Parameter | Name:
C00078 | SC: Tn field controller
Data type: UNSIGNED_16
Index: 24497
d
= 5FB1
h
Reset time Tn of the field controller for SC (servo control) mode
• After the motor to be used has been selected from the motor catalogue, the suitable value can be entered
automatically.
Setting range (min. value | unit | max. value) Lenze setting
0.1 ms 6000.0 256.0 ms
; Read access ; Write access  CINH  PLC STOP  No transfer  COM ; MOT Scaling factor: 10
