Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010 L 83
8400 HighLine | Parameter setting & configuration
Device control (DCTRL)
Device states
4.2.7 OperationEnabled
The drive controller is in this device state if the controller inhibit is deactivated and no error
("Trouble" or "TroubleQSP") has occured. The operation is enabled and the motor follows
the setpoint defined by the active application.
Depending on certain conditions, a state change takes place based on the
"OperationEnabled" device state.
Related topics:
wCANControl/wMCIControl control words
( 94)
4.2.8 Warning
This display may occur in all device states if a monitoring mode responds, the error
response "Warning" or "Warning locked" has been parameterised for.
If the error is no longer active, the previous device state is displayed.
LED DRIVE READY LED DRIVE ERROR Display in C00137 Display in status word 1 (C00150)
Bit 11 Bit 10 Bit 9 Bit 8
Off OperationEnabled0101
Change condition Changeover to the device state
Control bit "EnableOperation" of a control channel = "0"
OR terminal RFR = LOW level (controller inhibit).
SwitchedON
Control bit "SwitchOn" = "0". ReadyToSwitchON
Undervoltage in the DC bus. Trouble/Fault (depending onC00600/1)
Error with error response "Trouble" occurs. Trouble
Error with error response "TroubleQSP" occurs. TroubleQSP
LED DRIVE READY LED DRIVE ERROR Display in C00137 Display in status word 1 (C00150)
Bit 11 Bit 10 Bit 9 Bit 8
Warning 0110
