8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list
802 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
12.2.1.2 Selection list - digital signals
This selection list is relevant for the
following parameters:
Parameter
C00411 L_SignalMonitor_b: Signal sources
C00621
System connection list: Bool
C00701
LA_NCtrl: Digital connection list
C00711
LA_TabPos: Digital connection list
C00761
LA_SwitchPos: Digital connection list
Selection list - digital signals
0 Not connected
1000 LA_nCtrl_bDriveReady
1001 LA_nCtrl_bDriveFail
1002 LA_nCtrl_bCInhActive
1003 LA_nCtrl_bQSPIsActive
1004 LA_nCtrl_bSpeedCcw
1005 LA_nCtrl_bSpeedActCompare
1008 LA_nCtrl_bGPDigitalDelayOut
1009 LA_nCtrl_bGPLogicOut
1010 LA_nCtrl_bGPSignalOut1
1011 LA_nCtrl_bGPSignalOut2
1012 LA_nCtrl_bGPSignalOut3
1013 LA_nCtrl_bGPSignalOut4
1014 LA_nCtrl_bOverLoadActive
1015 LA_nCtrl_bBrakeReleaseOut
1016 LA_nCtrl_bBrakeReleased
1017 LA_nCtrl_bGPCompareOut
1018 LA_nCtrl_bUnderLoadActive
1019 LA_nCtrl_bImaxActive
1020 LA_nCtrl_bSpeedSetReached
1021 LA_nCtrl_bSpeedActEqSet
1022 LA_nCtrl_bGPDFlipFlopOut
1023 LA_nCtrl_bGPDFlipFlopNegOut
1029 LA_nCtrl_bFreeOut1
1030 LA_nCtrl_bFreeOut2
1031 LA_nCtrl_bFreeOut3
1032 LA_nCtrl_bFreeOut4
1033 LA_nCtrl_bFreeOut5
1034 LA_nCtrl_bFreeOut6
1035 LA_nCtrl_bFreeOut7
1036 LA_nCtrl_bFreeOut8
1100 LA_TabPos_bDriveFail
1101 LA_TabPos_bDriveReady
1102 LA_TabPos_bCInhActive
1103 LA_TabPos_bQSPIsActive
1104 LA_TabPos_bSpeedCcw
1105 LA_TabPos_bSpeedActCompare
1106 LA_TabPos_bImaxActive
1107 LA_TabPos_bSpeedSetReached
1108 LA_TabPos_bMBrakeReleaseOut
1109 LA_TabPos_bMBrakeReleased
1110 LA_TabPos_bHomeDone
1111 LA_TabPos_bHomePosAvailable
1112 LA_TabPos_bProfileDone
1113 LA_TabPos_bProfileBusy
1114 LA_TabPos_bAccelerating
1115 LA_TabPos_bConstantDuty
1116 LA_TabPos_bDecelerating
1117 LA_TabPos_bDwellTime
1118 LA_TabPos_bInTarget
1119 LA_TabPos_bGPDigitalDelayOut
1120 LA_TabPos_bGPLogicOut
1121 LA_TabPos_bGPCompareOut
1122 LA_TabPos_bGPSignalOut1
1123 LA_TabPos_bGPSignalOut2
1124 LA_TabPos_bGPSignalOut3
1125 LA_TabPos_bGPSignalOut4
1126 LA_TabPos_bGPDFlipFlop_Out
1127 LA_TabPos_bGPDFlipFlop_NegOut
1128 LA_TabPos_bGPCounter1Equal
1129 LA_TabPos_bFreeOut1
1130 LA_TabPos_bFreeOut2
1131 LA_TabPos_bFreeOut3
1132 LA_TabPos_bFreeOut4
1133 LA_TabPos_bFreeOut5
1134 LA_TabPos_bFreeOut6
1135 LA_TabPos_bFreeOut7
1136 LA_TabPos_bFreeOut8
1200 LA_SwitchPos_bDriveFail
1201 LA_SwitchPos_bWarningActive
1202 LA_SwitchPos_bSafeTorqueOff
1203 LA_SwitchPos_bDriveReady
1204 LA_SwitchPos_bCInhActive
1205 LA_SwitchPos_bImpIsActive
1206 LA_SwitchPos_bQSPIsActive
1207 LA_SwitchPos_bSpeedCcw
1208 LA_SwitchPos_bSpeedActCompare
1209 LA_SwitchPos_bImaxActive
1210 LA_SwitchPos_bSpeedSetReached
1211 LA_SwitchPos_bSpeedActEqSet
1212 LA_SwitchPos_bBrakeReleaseOut
1213 LA_SwitchPos_bBrakeReleased
1214 LA_SwitchPos_bGPDigitalDelayOut
1215 LA_SwitchPos_bGPLogicOut
1216 LA_SwitchPos_bGPCompareOut
1217 LA_SwitchPos_bGPDFlipFlop_Out
1218 LA_SwitchPos_bGPDFlipFlop_NegOut
1219 LA_SwitchPos_bGPSignalOut1
1220 LA_SwitchPos_bGPSignalOut2
1221 LA_SwitchPos_bGPSignalOut3
1222 LA_SwitchPos_bGPSignalOut4
Selection list - digital signals
