Lenze E84AVHC Series - C00560 | Fan switching status; C00561 | Fan failure; C00565 | Resp. to mains phase failure; C00566 | Resp. to fan failure

8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00560
668 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
C00560
C00561
C00565
C00566
Parameter | Name:
C00560 | Fan switching status
Data type: UNSIGNED_8
Index: 24015
d
= 5DCF
h
Function status display of device fan
Selection list
0 Off
1 On
2 No fan
Subcodes Info
C00560/1 Switching status - internal fan
C00560/2 Switching status - heatsink fan
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00561 | Fan failure
Data type: UNSIGNED_8
Index: 24014
d
= 5DCE
h
Error status display of device fan
Selection list
0 No error
1 Fault
Subcodes Info
C00561/1 Internal fan failure
C00561/2 Heatsink fan failure
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00565 | Resp. to mains phase failure
Data type: UNSIGNED_8
Index: 24010
d
= 5DCA
h
Response to the failure of mains-phases
Selection list (Lenze setting printed in bold)
0 No Reaction
1Fault
5 Warning
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00566 | Resp. to fan failure
Data type: UNSIGNED_8
Index: 24009
d
= 5DC9
h
Response to the detection of a fan failure
Selection list (Lenze setting printed in bold)
0 No Reaction
1Fault
5 Warning
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
