8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00973
756 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
C00973
C00985
C00986
C00987
C00988
Parameter | Name:
C00973 | VFC: Ti V/f +encoder
Data type: UNSIGNED_16
Index: 23602
d
= 5C32
h
Integral time constant of the slip regulator for VFCplus+encoder mode
• Usually, the time constant should be selected between 20 ms (high dynamic performance) and 200 ms (low
dynamic performance).
Setting range (min. value | unit | max. value) Lenze setting
0.0 ms 6000.0 100.0 ms
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
Parameter | Name:
C00985 | SLVC: Field current controller gain
Data type: INTEGER_16
Index: 23590
d
= 5C26
h
Gain of the direct-axis current difference (Id) between setpoint and actual current for the voltage model of the SLVC
(vector control) mode
• The gain should be selected between 0 and 1 %.
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 10.00 0.50 %
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00986 | SLVC: Cross current controller gain
Data type: INTEGER_16
Index: 23589
d
= 5C25
h
Gain of the I-Q-difference for the voltage model of the SLVC (vector control) mode
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 10.00 0.00 %
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00987 | Inverter motor brake: nAdd
Data type: INTEGER_16
Index: 23588
d
= 5C24
h
As of version 04.00.00
Speed lift which is added in pulses to the deceleration ramp if motor braking is carried out.
Inverter motor brake
Setting range (min. value | unit | max. value) Lenze setting
0 rpm 1000 80 rpm
; Read access ; Write access  CINH  PLC STOP  No transfer  COM ; MOT Scaling factor: 1
Parameter | Name:
C00988 | Inverter motor brake: PT1 filter time
Data type: INTEGER_16
Index: 23587
d
= 5C23
h
As of version 04.00.00
PT1 filter time for smoothing the speed lift which is added in pulses (C00987
)
Inverter motor brake
Setting range (min. value | unit | max. value) Lenze setting
0.0 ms 100.0 0.0 ms
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
