Lenze E84AVHC Series - C00246 | L_PCTRL_1: Internal actual value nAct_a; C00249 | L_PT1_1: Time constant; C00250 | L_PT1 2-3: Time constant; C00251 | L_DT1_1: Time constant

8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00246
632 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
C00246
C00249
C00250
C00251
C00252
Parameter | Name:
C00246 | L_PCTRL_1: Internal actual value nAct_a
Data type: INTEGER_16
Index: 24329
d
= 5F09
h
As of version 04.00.00
FB L_PCTRL_1
: Display of the internal actual value
Display range (min. value | unit | max. value)
-199.99 % 199.99
; Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00249 | L_PT1_1: Time constant
Data type: UNSIGNED_16
Index: 24326
d
= 5F06
h
FB L_PT1_1: Time constant Tn
Setting range (min. value | unit | max. value) Lenze setting
1 ms 5000 2000 ms
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00250 | L_PT1 2-3: Time constant
Data type: INTEGER_16
Index: 24325
d
= 5F05
h
Setting range (min. value | unit | max. value)
1 ms 5000
Subcodes Lenze setting Info
C00250/1 2000 ms L_PT1_2
: Time constant
C00250/2 2000 ms L_PT1_3
: Time constant
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00251 | L_DT1_1: Time constant
Data type: INTEGER_16
Index: 24324
d
= 5F04
h
FB L_DT1_1: Time constant Tn
Setting range (min. value | unit | max. value) Lenze setting
10 ms 5000 1000 ms
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00252 | L_DT1_1: Gain
Data type: INTEGER_16
Index: 24323
d
= 5F03
h
FB L_DT1_1: Gain factor Vp
Setting range (min. value | unit | max. value) Lenze setting
-320.00 320.00 1.00
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
