Lenze E84AVHC Series - C00905 | Motor phases: Direction of rotation; C00909 | Speed limitation; C00910 | Frequency limitation; C00915 | Motor cable length

8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00905
750 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
C00905
C00909
C00910
C00915
C00916
Parameter | Name:
C00905 | Motor phases: Direction of rotation
Data type: UNSIGNED_8
Index: 23670
d
= 5C76
h
As of version 04.00.00
To correct such misconnected motor phases, the rotating field of the controller's output can be reversed by selecting
"1: Inverted". In this case, a phase will be reversed at the output of the inverter.
Selection list (Lenze setting printed in bold)
0 not inverted
1inverted
; Read access ; Write access ; CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00909 | Speed limitation
Data type: INTEGER_16
Index: 23666
d
= 5C72
h
Maximum positive/negative speed for all operating modes
Setting range (min. value | unit | max. value)
0.00 % 175.00
Subcodes Lenze setting Info
C00909/1 120.00 % Max. pos. speed
C00909/2 120.00 % Max. neg. speed
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00910 | Frequency limitation
Data type: UNSIGNED_16
Index: 23665
d
= 5C71
h
Maximum positive/negative output frequency for all operating modes
Setting range (min. value | unit | max. value)
0 Hz 1000
Subcodes Lenze setting Info
C00910/1 1000 Hz Max. pos. output frequency
C00910/2 1000 Hz Max. neg. output frequency
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00915 | Motor cable length
Data type: UNSIGNED_16
Index: 23660
d
= 5C6C
h
Single motor cable length for calculating the motor cable resistance
• The calculated motor cable resistance is displayed in C00917
.
Setting range (min. value | unit | max. value) Lenze setting
0.0 m 1000.0 5.0 m
; Read access ; Write access  CINH  PLC STOP  No transfer  COM ; MOT Scaling factor: 10
Parameter | Name:
C00916 | Motor cable cross-section
Data type: UNSIGNED_16
Index: 23659
d
= 5C6B
h
Motor cable cross-section of a phase/cable for calculating the motor cable resistance
• The calculated motor cable resistance is displayed in C00917
.
Setting range (min. value | unit | max. value) Lenze setting
0.50 mm^2 100.00 6.00 mm^2
; Read access ; Write access  CINH  PLC STOP  No transfer  COM ; MOT Scaling factor: 100
