Firmware 05.00 - DMS 4.2 EN - 02/2010 L 535
8400 HighLine | Parameter setting & configuration
System bus "CAN on board"
Parameter data transfer
10.8.2.4 Error messages
In the event of an error, the addressed node generates a telegram with the "Error response"
(0x80) command.
The telegram includes the index and subindex of the code where the error occurred.
The error code is entered in bytes 5 ... 8.
The error codes are standardised according to DS301, V4.02.
The representation of the error codes is provided in reverse read direction (see
example below).
Example
Representation of error code "0x06 04 00 41" in bytes 5 ... 8:
1st byte 2nd byte 3rd byte 4th byte 5th byte 6th byte 7th byte 8th byte
Command Index Subindex Error code
0x80
(128)
LOW byte HIGH byte Low word High word
LOW byte HIGH byte LOW byte HIGH byte
1st byte 2nd byte 3rd byte 4th byte 5th byte 6th byte 7th byte 8th byte
Command Index Subindex Error code
0x41 0x00 0x04 0x06
