Firmware 05.00 - DMS 4.2 EN - 02/2010 L 351
8400 HighLine | Parameter setting & configuration
Technology applications
TA "Switch-off positioning"
7.6.4 Setting parameters (short overview)
Parameter Info Lenze setting
Value Unit
C00011 Appl.: Reference speed 1500 rpm
C00012
Accel. time - main setpoint 2.000 s
C00013
Decel. time - main setpoint 2.000 s
C00105
Deceleration time - quick stop 2.000 s
C00039/1
Fixed setpoint 1 40.00 %
C00039/2
Fixed setpoint 2 60.00 %
C00039/3
Fixed setpoint 3 80.00 %
C00039/4...15
Fixed setpoint 4 ... 15 0.00 %
C00101/1...15
Additional acceleration time 1 ... 15 0.000 s
C00103/1...15
Additional deceleration time 1 ... 15 0.000 s
C00105
Deceleration time - quick stop 2.000 s
C00106
Auto-DCB: Hold time 0.500 s
C00107
DCB: Hold time 999.000 s
C00134
Ramp rounding - main setpoint 0: Off
C00182
S-ramp time PT1 20.00 s
C00190
Setpoint arithmetic 0: NOut = NSet
C00220
Accel. time - add. setpoint 0.000 s
C00221
Decel. time - add. setpoint 0.000 s
C00241
L_NSet_1: Hyst. NSet reached 0.50 %
C00488/1
InputSens.SlowDown1 0: Level
C00488/2
InputSens.Stop1 0: Level
C00488/3
InputSens.SlowDown2 0: Level
C00488/4
InputSens.Stop2 0: Level
C00488/5
InputSens.SlowDown3 0: Level
C00488/6
InputSens.Stop3 0: Level
C00632/1 L_NSet_1: Blocking speed 1 max 0.00 %
C00632/2
L_NSet_1: Blocking speed 2 max 0.00 %
C00632/3
L_NSet_1: max. skip frequency 3 0.00 %
C00633/1 L_NSet_1: Blocking speed 1 min 0.00 %
C00633/2
L_NSet_1: Blocking speed 2 min 0.00 %
C00039/3
L_NSet_1: Blocking speed 3 min 0.00 %
C00635
L_NSet_1: nMaxLimit 199.99 %
C00636
L_NSet_1: nMinLimit -199.99 %
C00670
L_OffsetGainP_1: Gain 1.0000
C00671
L_OffsetGainP_2: gain 1.0000
C00672
L_OffsetGainP_3: gain 1.0000
C00696
L_OffsetGainP_1: Offset 0.00 %
C00697
L_OffsetGainP_2: Offset 0.00 %
C00698
L_OffsetGainP_3: Offset 0.00 %
C00800
L_MPot_1: Upper limit 100.00 %
C00801
L_MPot_1: Lower limit -100.00 %
C00802
L_MPot_1: Acceleration time 10.0 s
