Lenze E84AVHC Series User Manual

Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010 L 691
8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00691
C00691
C00692
C00693
C00694
Parameter | Name:
C00691 | L_Compare_3: Hysteresis
Data type: INTEGER_16
Index: 23884
d
= 5D4C
h
FB L_Compare_3: Hysteresis for the comparison function selected in C00690
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 100.00 0.00 %
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00692 | L_Compare_3: Window
Data type: INTEGER_16
Index: 23883
d
= 5D4B
h
FB L_Compare_3: Window for the comparison function selected in C00690
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 100.00 0.00 %
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00693 | L_Compare 4-5: Fct.
Data type: UNSIGNED_8
Index: 23882
d
= 5D4A
h
Comparison operation
• If the statement of the selected comparison operation is true, the binary output bOut is set to TRUE.
Selection list
1In1 = In2
2In1 > In2
3In1 < In2
4 |In1| = |In2|
5 |In1| > |In2|
6 |In1| < |In2|
Subcodes Lenze setting Info
C00693/1 1: In1 = In2 L_Compare_4
: Function
C00693/2 1: In1 = In2 L_Compare_5
: Function
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00694 | L_Compare 4-5: Hysteresis
Data type: INTEGER_16
Index: 23881
d
= 5D49
h
Hysteresis for the comparison function selected in C00693
Setting range (min. value | unit | max. value)
0.00 % 100.00
Subcodes Lenze setting Info
C00694/1 0.00 % L_Compare_4
: Hysteresis
C00694/2 0.00 % L_Compare_5
: Hysteresis
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
