Lenze E84AVHC Series - C00609 | Resp. to maximum current; C00620 | System connection list: 16-bit

Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010 L 677
8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00609
C00609
C00610
C00611
C00612
C00613
C00615
C00617
C00620
Parameter | Name:
C00609 | Resp. to maximum current
Data type: UNSIGNED_8
Index: 23966
d
= 5D9E
h
Response if the maximum current (C00022, C00023) is reached.
Selection list (Lenze setting printed in bold)
0No Reaction
1Fault
5 Warning
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00610 | 16-bit connection table
Data type: UNSIGNED_16
Index: 23965
d
= 5D9D
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00611 | Bool connection table
Data type: UNSIGNED_16
Index: 23964
d
= 5D9C
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00612 | 32-bit connection table
Data type: UNSIGNED_16
Index: 23963
d
= 5D9B
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00613 | Connect. table 16-bit AdditionalFBsHL
Data type: UNSIGNED_16
Index: 23962
d
= 5D9A
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00615 | Connect. table Bool AdditionalFBsHL
Data type: UNSIGNED_16
Index: 23960
d
= 5D98
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00617 | Connect. table 32-bit AdditionalFBsHL
Data type: UNSIGNED_16
Index: 23958
d
= 5D96
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00620 | System connection list: 16-bit
Data type: UNSIGNED_16
Index: 23955
d
= 5D93
h
Connection parameters: 16-bit inputs
• Selection of the 16-bit output signals for connection with the 16-bit input signals.
• The selection list contains all 16-bit output signals which can be assigned to the 16-bit inputs mapped by the
subcodes.
Selection list
See selection list - analog signals
Subcodes Lenze setting Info
C00620/1 1003: LA_nCtrl_nMotorSpeedAct_a LS_AnalogOutput: nOut1_a (V)
C00620/2 0: Not connected LP_CanOut1
: wState
C00620/3 0: Not connected LP_CanOut1
: wOut2
C00620/4 0: Not connected LP_CanOut1
: wOut3
C00620/5 0: Not connected LP_CanOut1
: wOut4
