Page #642 background image
8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00349
642 L Firmware 05.00 - DMS 4.2 EN - 02/2010
C00349
C00350
Parameter | Name:
C00349 | CAN setting - DIP switch
Data type: UNSIGNED_16
Index: 24226
d
= 5EA2
h
DIP switch setting during last mains power-on
System bus "CAN on board"
Display area (min. hex value | max. hex value)
0x0000 0xFFFF
Value is bit-coded:
Bit 0 Node address 1
Bit 1 Node address 2
Bit 2 Node address 4
Bit 3 Node address 8
Bit 4 Node address 16
Bit 5 Node address 32
Bit 6 Node address 64
Bit 7 Baud rate 1
Bit 8 Baud rate 2
Bit 9 Baud rate 4
Bit 10 Reserved
Bit 11 Reserved
Bit 12 Reserved
Bit 13 Reserved
Bit 14 Reserved
Bit 15 DIP switch at 24V-ON accepted
; Read access Write access CINH PLC STOP ; No transfer COM MOT
Parameter | Name:
C00350 | CAN node address
Data type: UNSIGNED_8
Index: 24225
d
= 5EA1
h
Setting of the node address via parameters
The node address can only be parameterised if the node address "0" is set via the DIP switches.
A change of the node address will only become effective after a CAN reset node.
System bus "CAN on board"
Setting range (min. value | unit | max. value) Lenze setting
1631
; Read access ; Write access CINH PLC STOP No transfer ; COM MOT Scaling factor: 1
