Firmware 05.00 - DMS 4.2 EN - 02/2010 L 873
8400 HighLine | Parameter setting & configuration
Function library
Function blocks
L_ConvW_1
L_ConvW_2
L_ConvW_3
L_ConvW_4
2 μs ... enables parameterisable conversion between analog signal forms.
This FB is only available from version 04.00.00.
L_ConvWordsToDInt_1
L_ConvWordsToDInt_2
L_ConvWordsToDInt_3
3 μs ... converts two inputs values of the type "WORD" into an output value of
the type "DINT".
L_ConvWordToBits_1
L_ConvWordToBits_2
L_ConvWordToBits_3
3 μs ... converts an input value of "WORD" type into 16 individual binary
signals.
L_Counter_1
L_Counter_2
L_Counter_3
3 μs ... is a digital upcounter and downcounter.
L_Curve_1
4 μs ... can optionally display a characteristic function or a curve function
y=f(x), the X axis being the input signal and the Y axis being the output
signal.
This FB is only available from version 04.00.00.
L_DFlipFlop_1
L_DFlipFlop_2
3 μs ... provides two stable states depending on the input signals.
L_DigitalDelay_1
L_DigitalDelay_2
L_DigitalDelay_3
2 μs ... delays binary signals.
L_DigitalLogic_1
L_DigitalLogic_2
2 μs ... provides a binary output signal which is generated by the logic
combination of three input signals.
L_DigitalLogic5_1
L_DigitalLogic5_2
2 μs ... provides a binary output signal which is generated by the logic
combination of five input signals.
L_DT1_1
3 μs ...differentiates signals. The function block can, for instance, be used to
apply an acceleration (dv/dt).
L_FixSet_a_1
2 μs ... outputs one of 16 parameterisable analog signals.
This FB is only available from version 04.00.00.
L_FixSet_w_1
L_FixSet_w_2
2 μs ... outputs one of 16 parameterisable data words.
This FB is only available from version 04.00.00.
L_GainOffset_1
L_GainOffset_2
L_GainOffset_3
3 μs ... can amplify an analog input signal and then add an offset to it.
Gain and offset can be set via FB inputs.
L_GainOffsetP_1
L_GainOffsetP_2
L_GainOffsetP_3
3 μs ... can amplify an analog input signal and then add an offset to it.
Gain and offset can be set via parameters.
L_GainOffsetPhiP_1
L_GainOffsetPhiP_2
3 μs ... can amplify an angle signal and then add an offset to it.
Gain and offset can be set via parameters.
L_Interpolator_1
5 μs ... can interpolate a position setpoint and/or an analog value e.g. to
compensate for larger bus transmission cycles or to continue signal
characteristics if data telegrams are missing.
This FB is only available from version 04.00.00.
L_JogCtrlExtension_1
5 μs ... can be connected upstream to the L_NSet ramp generator to
implement a switch-off positioning at limit switch.
L_Limit_1
L_Limit_2
3 μs ... limits an analog input signal to an adjustable value range.
L_LimitPhi_1
L_LimitPhi_2
L_LimitPhi_3
3 μs ... limits an angle signal to an adjustable value range.
L_MckCtrlInterface_1
5 μs ... provides the application with process inputs for controlling various
basic functions of the Motion Control Kernel. MCKInterface
( 374)
Function block Runtime Function
