8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00712
700 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
C00712
C00715
C00716
C00717
C00711/43 0: Not connected LA_TabPos
: bMckOperationMode_4
(control input for MCK operating mode changeover
valency 4)
C00711/44 0: Not connected LA_TabPos
: bMckOperationMode_8
(control input for MCK operating mode changeover
valency 8)
C00711/45 0: Not connected LA_TabPos
: bPosProfileNo_1
(control input for selection of profile number valency 1)
C00711/46 0: Not connected LA_TabPos
: bPosProfileNo_2
(control input for selection of profile number valency 2)
C00711/47 0: Not connected LA_TabPos
: bPosProfileNo_4
(control input for selection of profile number valency 4)
C00711/48 0: Not connected LA_TabPos
: bPosProfileNo_8
(control input for selection of profile number valency 8)
C00711/49 0: Not connected LA_TabPos
: bFreeIn1
(input for binary user signal 1)
C00711/50 0: Not connected LA_TabPos
: bFreeIn2
(input for binary user signal 2)
C00711/51 0: Not connected LA_TabPos
: bFreeIn3
(input for binary user signal 3)
C00711/52 0: Not connected LA_TabPos
: bFreeIn4
(input for binary user signal 4)
C00711/53 0: Not connected LA_TabPos
: bFreeIn5
(input for binary user signal 5)
C00711/54 0: Not connected LA_TabPos
: bFreeIn6
(input for binary user signal 6)
C00711/55 0: Not connected LA_TabPos
: bFreeIn7
(input for binary user signal 7)
C00711/56 0: Not connected LA_TabPos
: bFreeIn8
(input for binary user signal 8)
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00711 | LA_TabPos: Analog connection list
Data type: UNSIGNED_16
Index: 23864
d
= 5D38
h
Parameter | Name:
C00712 | LA_TabPos: Connection list phi
Data type: UNSIGNED_16
Index: 23863
d
= 5D37
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00715 | LA_TabPos_Out: analog signal list
Data type: UNSIGNED_16
Index: 23860
d
= 5D34
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00716 | LA_TabPos_Out: Digital signal list
Data type: UNSIGNED_16
Index: 23859
d
= 5D33
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00717 | LA_TabPos_Out: Signal list phi
Data type: UNSIGNED_16
Index: 23858
d
= 5D32
h
This code is for device-internal use only and must not be written to by the user!
