8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00711
C00711/21 0: Not connected LA_TabPos: bHomeSetPosition
(control input for setting the home position)
C00711/22 0: Not connected LA_TabPos
: bHomeResetPosition
(control input for reset of "Home position known")
C00711/23 0: Not connected LA_TabPos
: bHomeMark
(input for pre-stop signal for homing)
C00711/24 0: Not connected LA_TabPos
: bPosSetProfilePosition
(control input for accepting the profile position in the
profile data set)
C00711/25 0: Not connected LA_TabPos
: bPosSetActualPosition
(control input for accepting the current position in the
profile data set)
C00711/26 0: Not connected LA_TabPos
: bPosExecute
(control input for positioning start)
C00711/27 0: Not connected LA_TabPos
: bPosFinishTarget
(control input for completion of positioning to target
position)
C00711/28 0: Not connected LA_TabPos
: bPosDisableFollowProfile
(control input for suppression of sequence profile
linkage)
C00711/29 0: Not connected LA_TabPos
: bPosStop
(control input for interruption of profile generation by
ramp-down procedure)
C00711/30 0: Not connected LA_TabPos
: bGPAnalogSwitchSet
(control input for analog-value selector change-over)
C00711/31 0: Not connected LA_TabPos
: bGPDigitalDelayIn
(input for digital signal with time delay)
C00711/32 0: Not connected LA_TabPos
: bGPLogicIn1
(input signal 1 for digital logic)
C00711/33 0: Not connected LA_TabPos
: bGPLogicIn2
(input signal 2 for digital logic)
C00711/34 0: Not connected LA_TabPos
: bGPLogicIn3
(input signal 3 for digital logic)
C00711/35 0: Not connected LA_TabPos
: bGPDFlipFlop_InD
(control input for DFlipFlop setting signal)
C00711/36 0: Not connected LA_TabPos
: bGPDFlipFlop_InClk
(control input for DFlipFlop clock signal)
C00711/37 0: Not connected LA_TabPos
: bGPDFlipFlop_InClr
(control input for DFlipFlop reset signal)
C00711/38 0: Not connected LA_TabPos
: bGPCounter1ClkUp
(control input for up-counting counter module 1)
C00711/39 0: Not connected LA_TabPos
: bGPCounter1ClkDown
(control input for down-counting counter module 1)
C00711/40 0: Not connected LA_TabPos
: bGPCounter1Load
(control input for load value acceptance in counter
module 1)
C00711/41 0: Not connected LA_TabPos
: bMckOperationMode_1
(control input for MCK operating mode changeover
valency 1)
C00711/42 0: Not connected LA_TabPos
: bMckOperationMode_2
(control input for MCK operating mode changeover
valency 2)
Parameter | Name:
C00711 | LA_TabPos: Analog connection list
Data type: UNSIGNED_16
Index: 23864
d
= 5D38
h
