Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010 L 1091
8400 HighLine | Parameter setting & configuration
Function library
System blocks | LS_WriteParamList
Outputs
Parameter
Identifier
Data type
Value/meaning
bDone
BOOL
"Writing of the parameter list completed" status signal
• The output is automatically reset to FALSE if writing via bExecute is activated
again.
TRUE Writing of the parameter list successfully completed.
FALSE The FALSE status can have the following meanings:
1.There is no active writing of the parameter list.
2.Writing of the parameter list has not been completed yet.
3.An error has occurred (if bFail = TRUE).
bFail
BOOL
"Error" status
TRUE An error has occurred (group signal).
• See display parameter (C01083
) for details.
Parameter Possible settings Info
C01082
Execute Mode
0 by Execute The writing of the parameter list is
activated by a FALSE/TRUE edge at
the bExecute input.
1 by Input Select The writing of the parameter list is
carried out if a change is made at the
select inputs and if the controller is
initialised.
C01083
Error status
•If bFail = TRUE:
Error status is displayed.
0No error
C01084
0 16 Error line
•If bFail = TRUE:
Display of the number of the list
entry at which the error occurred
(in connection with the value set
selected via bSelectWriteValue_1
and bSelectWriteValue_2).
C01085/1 ... 32
0,000 16000,000 Parameter list
• Parameter for entries 1 ... 32
Format:
<Code number>,<Subcode number>
Examples:
"12,000" = C00012; "26,001" = C00026/1
C01086/1 ... 32
-2147483647 2147483647 Parameter values - value set 1
• Parameter values for the
parameters defined in C01085/
1 ... 32.
C01087/1 ... 32
-2147483647 2147483647 Parameter values - value set 2
• Parameter values for the
parameters defined in C01085/
1 ... 32.
