Lenze E84AVHC Series User Manual

Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010 L 215
8400 HighLine | Parameter setting & configuration
Motor control (MCTRL)
Internal status signals | system block "LS_DeviceMonitor"
Outputs
Identifier
DIS code | data type
Value/meaning
bMctrlImpActive
BOOL
TRUE Pulse inhibit is active
bMctrlClampActive
BOOL
TRUE Clamp current limitation is active
bMctrlMotorPhaseFault
BOOL
TRUE Motor phase fault has been detected
bMctrlEncoderComFault
BOOL
TRUE Encoder error has been detected
bMctrlNmax
BOOL
TRUE Max. speed limitation is active
bMctrlTorqueMax
BOOL
TRUE Max. torque limitation is active
bMctrlFChopReduced
BOOL
TRUE PWM frequency reduction is active
bMctrlIxtOverload
BOOL
TRUE Device utilisation (Ixt) ≥ 100 %
nMctrlIxtRate_a
INT
Current device utilisation (Ixt)
• Scaling: 16384 ≡ 100 %
bMctrlI2xtOverload
BOOL
TRUE Thermal motor load (I2xt) ≥ 100 %
nMctrlI2xtRate_a
INT
Current thermal motor load (I2xt)
• Scaling: 16384 ≡ 100 %
bMctrlMotorPTC
BOOL
TRUE Temperature monitoring: An error has been detected
bMctrlMotorTemp
BOOL
TRUE Thermal motor overload
bMctrlHeatSinkTemp
BOOL
TRUE Thermal inverter overload
bMctrlMainsFault
BOOL
TRUE Mains phase failure/Mains failure
bMctrlFanFault
BOOL
TRUE Fan monitoring: An error has been detected
bMctrlNmaxForFChop
BOOL
TRUE The maximum field frequency for the respective switching
frequency has been exceeded.
bMctrlShortCircuit
BOOL
TRUE Motor short circuit has been detected
bMctrlEarthFault
BOOL
TRUE Earth fault has been detected
bMctrlUVDetected
BOOL
TRUE An undervoltage has been detected
bMctrlOVDetected
BOOL
TRUE An overvoltage has been detected
bMctrlBrakeChopper
BOOL
TRUE Brake chopper error
