8400 HighLine | Parameter setting & configuration
I/O terminals
Digital input terminals
226 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
Short overview of parameters for the counting inputs:
Parameter Info Lenze setting
Value Unit
Counting input DI1
C00115/1
Fct. DI 1/2 100kHz 0: DI1(6)=In / DI2(7)=In
C00621/3
LS_DigitalInput: bCountIn1_Reset 0: Not connected
C00621/4
LS_DigitalInput: bCountIn1_LoadStartValue 0: Not connected
C02840/1
CountIn1: Starting value 0 incr
C02840/2
CountIn1: Comp. value 65535 incr
C02841/1 CountIn1: Counter content - incr
C00443/1 DIx: Terminal level -
Counting input DI6
C00115/2
Fct. DI 6/7 10kHz 0: DI1(6)=In / DI2(7)=In
C00621/97
LS_DigitalInput: bCountIn6_Reset 0: Not connected
C00621/98
LS_DigitalInput: bCountIn6_LoadStartValue 0: Not connected
C02840/3
CountIn6: Starting value 0 incr
C02840/4
CountIn6: Comp. value 65535 incr
C02841/2 CountIn6: Counter content - incr
C00443/1 DIx: Terminal level -
Highlighted in grey = display parameter
