8400 HighLine | Parameter setting & configuration
I/O terminals
Digital output terminals
232 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
Short overview of parameters for the digital output terminals:
Related topics:
Configuring exception handling of the output terminals
( 244)
User-defined terminal assignment
( 245)
Electrical data
( 252)
Button Function
Indicates that the polarity of the output is HIGH active.
The polarity can be changed from HIGH active to LOW active by clicking on this button.
Indicates that the polarity of the output is LOW active.
The polarity can be changed from LOW active to HIGH active by clicking on this button.
Parameter Info Lenze setting
Value Unit
Digital outputs DO1/DO2
C00118
DOx: Inversion Bit coded
C00423/3
DO1 ON delay 0.000 s
C00423/4
DO1 OFF delay 0.000 s
C00423/5
DO2 ON delay 0.000 s
C00423/6
DO2 OFF delay 0.000 s
C00423/7
DO3 ON delay 0.000 s
C00423/8
DO3 OFF delay 0.000 s
C00444/1 DOx: Input level -
C00444/2 DOx: Terminal level -
High current output
C00423/9
DO "High Current" ON delay 0.000 s
C00423/10
DO "High Current" OFF delay 0.000 s
C00117 Status - brake output BD -
Relay output
C00423/1
Relay ON delay 0.000 s
C00423/2
Relay OFF delay 0.000 s
Digital outputs - terminal configuration
C00621/1
LS_DigitalOutput:bRelay 1001: LA_nCtrl_bDriveFail
C00621/2
LS_DigitalOutput:bOut1 1000: LA_nCtrl_bDriveReady
C00621/99
LS_DigitalOutput: bOut2 0: Not connected
C00621/100
LS_DigitalOutput: bOut3 0: Not connected
C00621/101
LS_DigitalOutput: bOut HighCurrent 0: Not connected
Highlighted in grey = display parameter
