8400 HighLine | Parameter setting & configuration
Technology applications
TA "Actuating drive speed"
272 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
nMotorTorqueAct_a
INT
Actual torque
• In the "VFC (+encoder)" operating mode of the motor control, this value is
determined from the current motor current and corresponds to the actual torque
only by approximation.
• Scaling: 16384 ≡ 100 % M
max
(C00057)
nDCVoltage_a
INT
Actual DC-bus voltage
• Scaling: 16384 ≡ 1000 V
nMotorVoltage_a
INT
Current motor voltage/inverter output voltage
• Scaling: 16384 ≡ 1000 V
MCK basic functions
bBrakeReleaseOut
BOOL
Holding brake control: Trigger signal for the holding brake control switching
element via a digital output
• Use bit 0 under C02582
to activate inverted switching element triggering.
FALSE Apply brake.
TRUE Release brake.
bBrakeReleased
BOOL
Holding brake control: Status signal of the brake control with regard to the release
and application times of the brake
FALSE Brake applied (when the brake application time has elapsed).
TRUE Brake released (when the brake release time has elapsed).
GP: GeneralPurpose
The following outputs are interconnected with logic/arithmetic functions on application level for free usage.
"GeneralPurpose" functions
nGPAnalogSwitchInOut_a
INT
Analog switch: Output signal
nGPArithmetikOut_a
INT
Arithmetic: Output signal
nGPMulDivOut_a
INT
Multiplication/Division: Output signal
bGPDigitalDelayOut
BOOL
Binary delay element: Output signal
bGPLogicOut
BOOL
Binary logic: Output signal
bGPCompareOut
BOOL
Analog comparison: Output signal
bGPSignalOut1
...
bGPSignalOut4
BOOL
Binary signal monitor: Output signals
• The signal sources to be output are selected in C00411/1...4
.
• A bit coded inversion of the output signals can be parameterised in C00412
.
nGPSignalOut1_a
...
nGPSignalOut4_a
BOOL
Analog signal monitor: Output signals
• The signal sources to be output are selected in C00410/1...4
.
• Gain and offset for each output signal can be parameterised in C00413/1...8
.
bGPDFlipFlop_Out
BOOL
D-FlipFlop: Output signal
bGPDFlipFlop_NegOut
BOOL
D-FlipFlop: Negated output signal
Free outputs
The following outputs can freely be interconnected on the application level.
The signals from the application level can be transferred to the I/O level via these outputs.
bFreeOut1 ... bFreeOut8
BOOL
Free outputs for digital signals
wFreeOut1 ... wFreeOut4
WORD
Free outputs for 16-bit signals
Identifier
Data type
Value/meaning
