8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list
20065 nPar16_a
32000 MCTRL_nMotorSpeedAct_a
32001 MCTRL_nOutputSpeedCtrl_a
32002 MCTRL_nInputJerkCtrl_a
32003 MCTRL_nInputTorqueCtrl_a
32004 MCTRL_nMotorTorqueAct_a
32005 MCTRL_nActualFluxx_a
32006 MCTRL_nDCVoltage_a
32007 MCTRL_nStatorCurrentIS_a
32008 MCTRL_nEffCurrentIq_a
32009 MCTRL_nReaktCurrentId_a
32010 MCTRL_wMaxMotorSpeed
32011 MCTRL_wMaxMotorTorque
32012 MCTRL_nMotorVoltage_a
32013 MCTRL_nMotorFreqAct_a
32014 MCTRL_nEffSpeedSetValue_a
32015 MCTRL_nIxTRate_a
32016 MCTRL_nI2xTRate_a
32017 MCTRL_nOutputPosCtrl_a
32018 MCTRL_nHlgSetValue_a
32019 MCTRL_nMotorSpeedAct_v
32020 MCTRL_nSpeedCtrlIAct_a
32100 DCTRL_wDeviceStateWord
32101 DCTRL_wDeviceAuxStateWord
32102 DCTRL_wDetermFailNoLow
32103 DCTRL_wDetermFailNoHigh
32104 DCTRL_wFailNo16Bit
32200 MCK_nSpeedSet_v
32201 MCK_nSpeedCtrlI_a
32202 MCK_nSpeedSetValue_a
32203 MCK_nTorqueSetValue_a
32204 MCK_wActProfileNo
32205 MCK_wFollowProfileNo
32206 MCK_wMotionState1
32207 MCK_wMotionState2
32208 MCK_wAuxState
32209 MCK_nPWMAngleOffset
32210 MCK_nTorqueLimitAdapt_a
32211 Reserved
34900 MCTRL_OszCh1
34901 MCTRL_OszCh2
34902 MCTRL_OszCh3
34903 MCTRL_OszCh4
34904 MCTRL_Status1
34905 MCTRL_Status2
34906 MCTRL_Status3
34907 HDW_24V
36000 L_Absolut _Out_1
36001 L_AddSub_Out_1
36002 L_OffsetGain_Out_1
36003 L_OffsetGain_Out_2
36004 L_OffsetGainPar_1
Selection list - analog signals
36005 L_OffsetGainPar_2
36006 L_GainOffset_Out_1
36007 L_GainOffset_Out_2
36008 L_GainOffsetPar_1
36009 L_GainOffsetPar_2
36010 L_Negation_Out_1
36011 L_Aritmethik_Out_1
36012 L_Aritmethik_Out_2
36013 L_AnalogSwitch_Out_1
36014 L_AnalogSwitch_Out_2
36015 L_AnalogSwitch_Out_3
36016 L_Limit_Out_1
36017 L_Limit_Out_2
36018 L_NSet_NOut_1
36019 L_MotorPoti_1_Out
36020 L_PCTRL_1_Out
36021 L_SigMonitor_a_Out1
36022 L_SigMonitor_a_Out2
36023 L_NLim_1_nOut_a
36024 L_Counter_1_wOut
36025 L_OffsetGainPar_3
36026 L_GainOffsetPar_3
36027 L_SigMonitor_a_Out3
36028 L_SigMonitor_a_Out4
36029 L_MulDiv_1_nOut_a
36030 L_NLim_1_wState
36031 L_NSet_1_wState
36032 L_NSet_1_nSetValue
36033 L_PT1_1_nOut_a
36034 L_Absolut _Out_2
36035 L_AnalogSwitch_4_Out
36036 L_AnalogSwitch_5_Out
36037 L_Aritmethik_3_Out
36038 L_Aritmethik_4_Out
36039 L_Aritmethik_5_Out
36045 L_GainOffset_Out_3
36053 L_MulDiv_2_nOut_a
36054 L_Negation_2_Out
36055 L_NLim_2_nOut_a
36056 L_NLim_2_wState
36057 L_OffsetGain_Out_3
36058 L_PT1_2_nOut_a
36059 L_PT1_3_nOut_a
36064 L_SampleHold_1_nOut_a
36065 L_SampleHold_2_nOut_a
36068 L_Counter_2_wOut
36069 L_Counter_3_wOut
36073 L_DT1_1_nOut_a
36074 L_ConvBitsToWord_1_wOut
36075 L_ConvBitsToWord_2_wOut
36076 L_ConvBitsToWord_3_wOut
36077 L_ConvDIntToWords_1_wOutLWord
Selection list - analog signals
