Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010 L 939
8400 HighLine | Parameter setting & configuration
Function library
Function blocks | L_Counter_3
Parameter
General function
Every FALSE/TRUE edge at the bClkUp input causes the block to count upwards by "1".
Every FALSE/TRUE edge at the bClkDown input causes the block to count downwards by
"1".
Function "Normal counting"
If the statement of the comparison mode selected in C01101/3
is true, the bCompare
output is set to TRUE.
Function "Auto reset"
If the statement of the comparison mode selected in C01101/3
is true, the bCompare
output is set to TRUE for 1 ms and the counter is reset to the wLdVal starting value.
Function "Manual reset"
If the statement of the comparison mode selected in C01101/3
is true, the bCompare
output is set to TRUE and the counter stops.
Edges at bClkUp and bClkDown are ignored.
The counter must be reset via the bLoad input.
Parameter Possible settings Info
C01100/3
Function selection
• Lenze setting: Normal counting
0 Normal counting
1Auto reset
2Manual reset
C01101/3
Selection of comparison operation
• Lenze setting: Counter
content ≥ comparison value
0 Counter content ≥ comparison value
1 Counter content ≤ comparison value
2 Counter content = comparison value
