8400 HighLine | Parameter setting & configuration
Function library
Function blocks | L_DigitalLogic5_2
958 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
Truth table for C00826 = 4
Example:
If in case of the signal combination bln1 =TRUE, bln2 =FALSE, bln3 =TRUE,
bIn4 =TRUE and bIn5 = TRUE, the output signal bOut is to be = TRUE, C00825/30
must be
set to "TRUE":
bIn5 bIn4 bIn3 bIn2 bIn1 Output signal bOut
FALSE FALSE FALSE FALSE FALSE C00827/1
(FALSE or TRUE)
FALSE FALSE FALSE FALSE TRUE C00827/2
(FALSE or TRUE)
FALSE FALSE FALSE TRUE FALSE C00827/3
(FALSE or TRUE)
... C00827/...
(FALSE or TRUE)
TRUE TRUE TRUE FALSE TRUE C00827/30
(FALSE or TRUE)
TRUE TRUE TRUE TRUE FALSE C00827/31
(FALSE or TRUE)
TRUE TRUE TRUE TRUE TRUE C00827/32
(FALSE or TRUE)
bIn5 bIn4 bIn3 bIn2 bIn1 Output signal bOut
TRUE TRUE TRUE FALSE TRUE C00827/30
(TRUE)
