Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 314/970
Display Message
Interface: Specifies all the ports on which LLDP-MED can be configured.
Link: Specifies the link status of the ports whether it is Up/Down.
ConfigMED: Specifies the LLDP-MED mode is enabled or disabled on this interface.
OperMED: Specifies the LLDP-MED TLVs are transmitted or not on this interface
ConfigNotify: Specifies the LLDP-MED topology notification mode of the interface.
TLVsTx: Specifies the LLDP-MED transmit TLV(s) that are included
6.12.1.10 show lldp med local-device detail
The user can go to the CLI Privilege Mode to display detailed information about the LLDP-MED
data, use the show lldp med local-device detail <unit/slot/port> Privilege command.
Syntax
show lldp med local-device detail <slot/port>
Default Setting
None
Command Mode
Privileged Exec
Display Message
Network Policies Specifies if network policy TLV is present in the LLDP frames.
Media Policy Application Type Specifies the application type. Types of application types
are unknown, voicesignaling, guestvoice, guestvoicesignalling, softphonevoice,
videoconferencing, streammingvideo, vidoesignalling. Each application type that is
received has the VLAN id, priority, DSCP, tagged bit status and unknown bit status. A port
may receive one or many such application types. If a network policy TLV has been
transmitted only then would this information be displayed.
Vlan ID Specifies the VLAN id associated with a particular policy type.
Priority Specifies the priority associated with a particular policy type.
DSCP Specifies the DSCP associated with a particular policy type.
Unknown Specifies the unknown bit associated with a particular policy type.
Tagged Specifies the tagged bit associated with a particular policy type.
Inventory Specifies if inventory TLV is present in LLDP frames.
Hardware Rev Specifies hardware version.
Firmware Rev Specifies Firmware version.
Software Rev Specifies Software version.
