Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 92/970
6.2.3.6 show interface switchport
This command displays VLAN port information.
Syntax
show interface switchport {<slot/port> | all}
<slot/port> - Interface number.
all – Display the entire table.
Default Setting
None
Command Mode
Privileged Exec
Display Message
Interface: Indicates by slot id and port number which port is controlled by the fields on this
line. It is possible to set the parameters for all ports by using the selectors on the top line.
Port VLAN ID: The VLAN ID that this port will assign to untagged frames or priority tagged
frames received on this port. The value must be for an existing VLAN. The factory default is
1.
Acceptable Frame Types: Specifies the types of frames that may be received on this port.
The options are 'VLAN only' and 'Admit All'. When set to 'VLAN only', untagged frames or
priority tagged frames received on this port are discarded. When set to 'Admit All', untagged
frames or priority tagged frames received on this port are accepted and assigned the value
of the Port VLAN ID for this port. With either option, VLAN tagged frames are forwarded in
accordance to the 802.1Q VLAN specification.
Ingress Filtering: May be enabled or disabled. When enabled, the frame is discarded if this
port is not a member of the VLAN with which this frame is associated. In a tagged frame, the
VLAN is identified by the VLAN ID in the tag. In an untagged frame, the VLAN is the Port
VLAN ID specified for the port that received this frame. When disabled, all frames are
forwarded in accordance with the 802.1Q VLAN bridge specification. The factory default is
disabled.
GVRP: May be enabled or disabled.
Default Priority: The 802.1p priority assigned to untagged packets arriving on the port.
6.2.3.7 vlan database
This command is used to enter VLAN Interface configuration mode
