Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 389/970
Policy Table.
Policy Instance Table Size Current/Max The current or maximum number of entries (rows)
in the Policy Instance Table.
Policy Attribute Table Size Current/Max The current or maximum number of entries (rows)
in the Policy Attribute Table.
Service Table Size Current/Max The current or maximum number of entries (rows) in the
Service Table.
6.18.5.3 show diffserv service
This command displays policy service information for the specified interface and direction.
Syntax
show diffserv service <slot/port> in
<slot/port> specifies a valid slot number and port number for the system. The direction
parameter indicates the interface direction of interest.
Default Setting
None
Command Mode
Privileged EXEC
Display Message
DiffServ Admin Mode The current setting of the DiffServ administrative mode. An attached
policy is only in effect on an interface while DiffServ is in an enabled mode.
Interface The slot number and port number of the interface (slot/port).
Direction The traffic direction of this interface service.
Operational Status The current operational status of this DiffServ service interface.
Policy Name The name of the policy attached to the interface in the indicated direction.
Policy Details Attached policy details, whose content is identical to that described for the
show poli
cy-map <policymapname> command
(content not repea
ted here for brev
ity).
6.18.5.4 show diffserv service brief
This command displays all interfaces in the system to which a DiffServ policy has been
attached. The direction parameter is optional; if specified, only services in the indicated
direction are shown.
