Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 943/970
Source Address - The network address that is combined with the source mask to identify
the sources for this entry.
Source Mask - The subnet mask to be combined with the source address to identify the
sources for this entry.
Upstream Neighbor - The address of the upstream neighbor (e.g., RPF neighbor) from
which IP datagrams from these sources are received.
Interface - The interface on which IP datagrams sent by these sources are received. A
value of 0 typically means the route is an aggregate for which no next-hop interface exists.
Metric - The distance in hops to the source subnet.
Expiry Time (secs)- The minimum amount of time remaining before this entry will be aged
out.
Up Time (secs)- The time since the route represented by this entry was learned by the
router.
Command Buttons
Refresh - Refresh the screen with the new data
11.2.7.2 Managing IGMP Protocol
11.2.7.2.1. Configuring IGMP Global Configuration Page
Configurable Data
Admin Mode - Select enable or disable from the pulldown menu to set the administrative
status of IGMP in the router to active or inactive. The default is disable.
Command Buttons
Submit - Send the updated configuration to the router. Configuration changes take effect
