UANTA COMPUTER INC.
Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 391/970
(only those policy attributes actually configured are displayed):
Class Name The name of this class.
Mark CoS Denotes the class of service value that is set in the 802.1p header of outbound
packets. This is not displayed if the mark cos was not specified.
Mark IP DSCP Denotes the mark/re-mark value used as the DSCP for traffic matching this
class. This is not displayed if mark ip description is not specified using the police-two-rate
command, or if policing is in use for the class under this policy.
Mark IP Precedence Denotes the mark/re-mark value used as the IP Precedence for traffic
matching this class. This is not displayed if either mark DSCP or policing is in use for the
class under this policy.
Policing Style This field denotes the style of policing, if any, used simple.
Committed Rate (Kbps) This field displays the committed rate, used in simple policing,
single-rate policing, and two-rate policing.
Committed Burst Size (KB) This field displays the committed burst size, used in simple
policing.
Conform Action The current setting for the action taken on a packet considered to conform
to the policing parameters. This is not displayed if policing is not in use for the class under
this policy.
Conform COS Value This field shows the priority mark value if the conform action is
markcos.
Conform DSCP Value This field shows the DSCP mark value if the conform action is
markdscp.
Conform IP Precedence Value This field shows the IP Precedence mark value if the
conform action is markprec.
Non-Conform Action The current setting for the action taken on a packet considered to not
conform to the policing parameters. This is not displayed if policing not in use for the class
under this policy.
Non-Conform DSCP Value This field displays the DSCP mark value if this action is
markdscp.
Non-Conform IP Precedence Value This field displays the IP Precedence mark value if this
action is markprec.
Bandwidth This field displays the minimum amount of bandwidth reserved in either percent
or kilobits-per-second.
Policy Name The name of this policy. (Note that the order in which the policies are displayed
is not necessarily the same order in which they were created.)
Policy Type The policy type, namely whether it is an inbound or outbound policy definition.
Class Members List of all class names associated with this policy.
6.18.5.6 show policy-map interface
This command displays policy-oriented statistics information for the specified interface and
direction.
Syntax
