UANT
A
COMPUTER INC.
Layer
2,3,IPv6+QoS
Sw
itch
___________________________________________________________________________
__
Layer 2,3,
IPv6+QoS Net
work Switch User Manual V
ersion 0.1
Page: 363
/970
Default Setting
None
Command Mode
Privileged Exec
6.17.14
hostname
This command is used
to set the promp
t string.
Syntax
hostname <prompt_s
tring>
< prompt_string >
-
Prompt strin
g.
Default Setting
Quanta
Command Mode
Privileged Ex
ec
6.17.15
quit
This command is used
to exit a CLI session
.
Syntax
quit
Default Setting
None
Command Mode
Privileged Exec
362
364
Table of Contents
Default Chapter
3
Table of Contents
3
1 Introduction
33
Switch Description
33
Features
33
Front-Panel Components
34
LED Indicators
34
Rear Panel Description
34
Management Options
35
Web-Based Management Interface
35
Command Line Console Interface through the Serial Port or Telnet
35
SNMP-Based Management
35
2 Installation and Quick Startup
38
Package Contents
38
Switch Installation
38
Installing the Switch in a Rack
39
Quick Starting the Switch
40
System Information Setup
41
Quick Start up Software Version Information
41
Quick Start up Physical Port Data
41
Quick Start up User Account Management
42
Quick Start up IP Address
43
Quick Start up Uploading from Switch to Out-Of-Band PC (Only XMODEM).44
44
Quick Start up Downloading from Out-Of-Band PC to Switch (Only XMODEM)
44
Quick Start up Downloading from TFTP Server
45
Quick Start up Factory Defaults
45
3 Console and Telnet Administration Interface
47
Local Console Management
47
Set up Your Switch Using Console Access
47
Set up Your Switch Using Telnet Access
48
4 Web-Based Management Interface
49
Overview
49
How to Log in
49
Web-Based Management Menu
50
Main Menus
51
5 Command Line Interface Structure and Mode-Based CLI
55
CLI Command Format
55
CLI Mode-Based Topology
55
6 Switching Commands
58
System Information and Statistics Commands
58
Show Arp
58
Show Calendar
58
Show Eventlog
59
Show Running-Config
60
Show Sysinfo
60
Show Tech-Support
61
Show Hardware
61
Show Version
64
Show Loginsession
65
Device Configuration Commands
66
Interface
66
Show Interface Status
66
Show Interface Counters
67
Show Interface Status Description
67
Show Interface Switch
73
Interface
74
Speed-Duplex
74
Negotiate
75
Capabilities
76
Storm-Control Flowcontrol
78
Shutdown
79
Description
80
MDI
80
Note:the 10-Giga Interface will Not Provide the Following Command
80
L2 MAC Address and Multicast Forwarding Database Tables
81
Show Mac-Addr-Table
81
Show Mac-Addr-Table Count
82
Show Mac-Addr-Table Interface
82
Show Mac-Addr-Table Vlan
83
Show Mac-Address-Table Gmrp
84
Show Mac-Address-Table Igmpsnooping
85
Show Mac-Address-Table Multicast
85
Show Mac-Address-Table Stats
86
Show Mac-Address-Table Agetime
87
Mac-Address-Table Aging-Time
87
VLAN Management
88
Show Vlan
88
Show Vlan ID
89
Show Vlan Association Mac
90
Show Vlan Association Subnet
90
Show Protocol Group
91
Show Interface Switchport
92
Vlan Database
92
Vlan
93
Vlan Name
93
Vlan Association Mac
94
Vlan Association Subnet
94
Vlan Makestatic
95
Protocol Group
95
Switchport Acceptable-Frame-Type
96
Switchport Ingress-Filtering
97
Switchport Native Vlan
98
Switchport Allowed Vlan
99
Switchport Tagging
101
Switchport Priority
102
Switchport Protocol Group
103
Switchport Forbidden Vlan
105
Double VLAN Commands
106
Show Dvlan-Tunnel/ Dot1Q-Tunnel
106
Switchport Dvlan-Tunnel/ Dot1Q-Tunnel Ethertype
106
Switchport Dvlan-Tunnel/ Dot1Q-Tunnel
107
GVRP and Bridge Extension
108
Show Bridge-Ext
108
Show Gvrp Configuration
108
Show Gmrp Configuration
109
Show Garp Configuration
110
Bridge-Ext Gvrp
111
Bridge-Ext Gmrp
111
Switchport Gvrp
112
Switchport Gmrp
113
Garp Timer
114
IGMP Snooping
118
Show Commands
118
Configuration Commands
121
IGMP Snooping Querier
130
Show Commands
130
Configuration Commands
132
MLD Snooping
135
Show Commands
136
Configuration Commands
140
MLD Snooping Querier
146
Show Commands
146
Configuration Commands
148
Port Channel
150
Show Port-Channel
151
Port-Channel
152
Port-Channel Adminmode All
153
Staticcapability
153
Port-Channel Linktrap
154
Port-Channel Load-Balance
154
Port-Channel Name
156
Adminmode
156
Lacp
157
Channel-Group
158
Delete-Channel-Group
159
Storm Control
159
Show Storm-Control
160
Storm-Control Broadcast
161
Storm-Control Multicast
162
Storm-Control Unicast
163
Switchport Broadcast Packet-Rate
164
Switchport Multicast Packet-Rate
165
Switchport Unicast Packet-Rate
166
L2 Priority
168
Show Queue Cos-Map
168
Queue Cos-Map
168
Port Mirror
169
Show Port-Monitor Session
169
Port-Monitor Session
170
Port-Monitor Session Mode
171
Management Commands
171
Network Commands
171
Show Ip Interface
171
Show Ip Filter
172
Interface Vlan
173
Mtu
173
Ip Address
174
Ip Default-Gateway
174
Ip Address Protocol
175
Ip Filter
175
Serial Interface Commands
176
Show Line Console
176
Line Console
177
Baudrate
178
Exec-Timeout
178
Password-Threshold
179
Silent-Time
179
Telnet
180
Telnet Session Commands
180
Terminal Length
180
Line Vty
181
Show Line Vty
181
Exec-Timeout
182
Maxsessions
183
Password-Threshold
183
Terminal Length
183
Server Enable
184
Sessions
184
Telnet Sessions
185
Telnet Maxsessions
186
Telnet Exec-Timeout
186
Show Telnet
187
SNMP Server Commands
188
Show Snmp
188
Show Trapflags
188
Snmp-Server Sysname
189
Snmp-Server Location
190
Snmp-Server Contact
190
Snmp-Server Community
191
Snmp-Server Host
193
Snmp-Server Enable Traps
194
SNMP Trap Commands
199
Show Snmptrap
199
Snmptrap Snmpversion
199
Snmptrap Link-Status
200
Snmptrap <Name> <Ipaddr> <Snmpversion
201
Snmptrap Ipaddr
202
Snmptrap Mode
202
HTTP Commands
203
Show Ip Http
203
Ip Javamode
204
Ip Http Port
204
Ip Http Server
205
Ip Http Secure-Port
205
Ip Http Secure-Server
206
Ip Http Secure-Protocol
206
Secure Shell (SSH) Commands
207
Show Ip Ssh
207
Ip Ssh
208
Ip Ssh Protocol
208
Ip Ssh Maxsessions
209
Ip Ssh Timeout
209
Http Session Hard-Timeout
210
Http Session Soft-Timeout
211
Http Secure-Session Soft-Timeout
211
Set Max Secure-Sessions
212
Set Max Sessions
212
DHCP Client Commands
213
Ip Dhcp Restart
213
Set Ip Http Java
213
DHCP Relay Commands
214
Ip Dhcp Client-Identifier
214
Show Bootpdhcprelay
214
Bootpdhcprelay Maxhopcount
215
Bootpdhcprelay Serverip
216
Sflow Commands
216
Show Sflow Information
216
Set Sflow Sampling Rate
217
Set Sflow Collector Address
218
Set Sflow Maximum Datagram Size
218
Set Sflow Maximum Header Size
218
Set Sflow Collector Port
219
Set Sflow Interval
219
Service Port Commands
220
Show Serviceport
220
Show Serviceport Ndp
220
Serviceport Ip
221
Serviceport Protocol
222
Spanning Tree Commands
223
Show Commands
223
Show Spanning-Tree
223
Show Spanning-Tree Interface
224
Show Spanning-Tree Mst
225
Show Spanning-Tree Vlan
225
Show Spanning-Tree Brief
229
Show Spanning-Tree Summary
229
Configuration Commands
230
Spanning-Tree
230
Spanning-Tree Protocol-Migration
230
Spanning-Tree Configuration
231
Spanning-Tree Mode
232
Spanning-Tree Forward-Time
233
Spanning-Tree Hello-Time
233
Spanning-Tree Max-Age
234
Spanning-Tree Max-Hops
235
Spanning-Tree Mst
235
Spanning-Tree Port Mode
239
Spanning-Tree Edgeport
240
System Log Management Commands
241
Show Commands
241
Show Logging
241
Show Logging Buffered
241
Show Logging Traplog
242
Configuration Commands
243
Logging Buffered
243
Show Logging Hosts
243
Logging Console
244
Logging Host
245
Logging Syslog
246
Clear Logging Buffered
247
Script Management Commands
248
Script Apply
248
Script Delete
248
Script List
249
Script Show
249
User Account Management Commands
250
Show Commands
250
Show Users
250
Configuration Commands
251
Show Users Account Information
251
Username
251
Set Encrypted the Password
252
Unlock a Locked User Acount
252
Username Snmpv3 Authentication
253
Set the Password Aging
254
Username Snmpv3 Encryption
254
Set the Password History
255
Set the Password Lock-Out Count
255
Set the Minimum Password Length
256
Security Commands
256
Show Commands
256
Show Users Authentication
256
Show Authentication
257
Show Authentication Users
257
Show Dot1X
258
Show Dot1X Detail
258
Show Dot1X Statistics
259
Show Dot1X Summary
260
Show Dot1X Users
261
Show Radius
262
Show Radius-Servers
262
Show Radius Accounting
263
Show Radius Statistics
264
Show Tacacs
265
Show Port-Security
266
Authentication Login
268
Configuration Commands
268
Username Defaultlogin
269
Dot1X Configuration Commands
270
Dot1X Initialize
270
Username Login
270
Dot1X Default-Login
271
Dot1X Login
271
Dot1X System-Auth-Control
272
Dot1X User
272
Dot1X Port-Control
273
Dot1X Host-Mode
274
Dot1X Max-Req
275
Dot1X Max-User
275
Dot1X Re-Authentication
276
Dot1X Re-Reauthenticate
276
Dot1X Timeout
277
Dot1X Guest Vlan
278
Dot1X Guest-Vlan
279
Dot1X Timeout Guest-Vlan-Period
279
Radius Accounting Mode
280
Radius Configuration Commands
280
Radius Server Attribute 4
280
Radius-Server Dead-Time
281
Radius-Server Host
281
Radius-Sever Key
282
Radius-Server Retransmit
283
Radius-Server Msgauth
284
Radius-Server Timeout
284
Radius-Server Primary
285
Tacacs Host
285
TACACS+ Configuration Commands
285
Tacacs Key
286
Tacacs Timeout
287
Port Security Configuration Commands
288
Port-Security
288
Port-Security Max-Dynamic
289
Port-Security Mac-Address
290
Port-Security Max-Static
290
Port-Security Mac-Address Move
291
Port-Security Violation Shutdown
291
CDP (Cisco Discovery Protocol) Commands
292
Show Cdp
292
Show Cdp Neighbors
292
Show Commands
292
Show Cdp Traffic
293
Cdp
294
Cdp Run
294
Configuration Commands
294
Cdp Timer
295
Cdp Holdtime
296
SNTP (Simple Network Time Protocol) Commands
296
Show Commands
296
Show Sntp
296
Configuration Commands
298
Sntp Broadcast Client Poll-Interval
298
Sntp Client Mode
299
Sntp Client Port
299
Sntp Unicast Client Poll-Interval
300
Sntp Unicast Client Poll-Timeout
300
Sntp Unicast Client Poll-Retry
301
Sntp Clock Timezone
302
Sntp Server
302
MAC-Based Voice VLAN Commands
303
Show Commands
303
Show Voice-Vlan
303
Configuration Commands
304
Show Voice Vlan
304
Voice-Vlan
304
Voice-Vlan Mac
305
Voice-Vlan Vlan
305
Voice Vlan
306
Voice Vlan (Interface Config)
306
Voice Vlan Data Priority
307
LLDP (Link Layer Discovery Protocol) Commands
308
Show Commands
308
Show Lldp
308
Show Lldp Interface
308
Show Lldp Statistics
309
Show Lldp Remote-Device
310
Show Lldp Remote-Device Detail
310
Show Lldp Local-Device
311
Show Lldp Local-Device Detail
312
Show Lldp Med
313
Show Lldp Med Interface
313
Show Lldp Med Local-Device Detail
314
Show Lldp Med Remote-Device
315
Show Lldp Med Remote-Device Detail
316
Configuration Commands
317
Lldp Notification
317
Lldp Notification-Interval
318
Lldp Receive
319
Lldp Transmit
319
Lldp Transmit-Mgmt
319
Lldp Transmit-Tlv
320
Lldp Med
321
Lldp Timers
321
Lldp Med Confignotification
322
Lldp Med Transmit-Tlv
322
Lldp Med All
323
Lldp Med Confignotification All
323
Lldp Med Faststartrepeatcount
324
Lldp Med Transmit-Tlv All
324
Denial of Service Commands
325
Show Commands
325
Show Dos-Control
325
Configuration Commands
326
Dos-Control Firstfrag
326
Dos-Control Sipdip
326
Dos-Control Tcpflag
327
Dos-Control Tcpfrag
327
Dos-Control Icmp
328
Dos-Control L4Port
328
Dos-Control Icmpv6
329
VTP (VLAN Trunking Protocol) Commands
330
Show Commands
330
Show Vtp Counters
330
Show Vtp Password
330
Show Vtp Status
331
Configuration Commands
332
Show Vtp Trunkport
332
Vtp
332
Vtp Domain
333
Vtp Mode
333
Vtp Password
334
Vtp Pruning
334
Vtp Trunkport
335
Protected Ports Commands
336
Configuration Commands
336
Show Commands
336
Show Switchport Protected
336
Switchport Protected
336
Static MAC Filtering Commands
338
Configuration Commands
338
Macfilter
338
Show Commands
338
Show Mac-Address-Table Static
338
Macfilter Addsrc
339
Macfilter Addsrc All
340
System Utilities
340
Clear
340
Clear Arp
340
Clear Eventlog
341
Clear Logging Buffered
341
Clear Traplog
341
Clear Config
342
Clear Pass
342
Clear Counters
343
Clear Dns
343
Clear Cdp
344
Clear Vlan
344
Clear Igmp Snooping
345
Clear Ip Filter
345
Clear Port-Channel
345
Clear Dot1X Statistics
346
Clear Radius Statistics
346
Clear Domain-List
347
Clear Hosts
347
Clear Ip Arp-Cache
348
Clear Port-Security Dynamic Address
348
Clear Lldp Remote-Data
349
Clear Lldp Statistics
349
Clear Ipv6 Neighbors
350
Clear Ipv6 Statistics
350
Enable Passwd
350
Clear Ipv6 Dhcp
351
Copy
352
Delete
354
Dir
355
Whichboot
355
Boot-System
356
Ping
356
Ping <Host
356
Ping Ipv6 <Ipv6-Address
357
Ping Ipv6 Interface
358
Traceroute
359
Logging Cli-Command
360
Traceroute Ipv6
360
Calendar Set
361
Reload
361
Configure
362
Disconnect
362
Hostname
363
Quit
363
Differentiated Service Command
364
Diffserv
365
General Commands
365
No Diffserv
365
Class Commands
366
Class-Map
366
Class-Map Rename
367
No Class-Map
367
Match any
368
Match Class-Map
368
Match Cos
369
No Match Class-Map
369
Match Destination-Address Mac
370
Match Dstip
370
Match Dstl4Port
371
Match Ethertype
372
Match Ip Dscp
372
Match Ip Precedence
373
Match Ip Tos
373
Match Protocol
374
Match Secondary-Cos
375
Match Secondary-Vlan
375
Match Source-Address Mac
376
Match Srcip
376
Match Srcl4Port
377
Match Vlan
377
Policy Commands
378
Assign-Queue
378
Drop
379
Mirror
379
Redirect
380
Conform-Color
380
Mark Cos
381
Class
381
No Class
382
Mark Ip-Dscp
382
Mark Ip-Precedence
383
Police-Simple
383
Policy-Map
384
Policy-Map Rename
384
Service Commands
385
Service-Policy
385
No Service-Policy
386
Show Commands
386
Show Class-Map
387
Show Diffserv
388
Show Diffserv Service
389
Show Diffserv Service Brief
389
Show Policy-Map
390
Show Policy-Map Interface
391
Show Service-Policy
393
ACL Command
393
Show Commands
394
Show Mac Access-Lists
394
Show Mac Access-Lists Name
394
Show Ip Access-Lists
395
Show Access-Lists Interface
396
Configuration Commands
397
Mac Access-List Extended
397
Mac Access-List Extended Rename
397
Mac Access-Group in
398
Access-List
399
Mac Access-List
399
No Access-List
400
Ip Access-Group
401
Ipv6 ACL Command
401
Show Commands
401
Show Ipv6 Access-Lists
401
Configuration Commands
402
Ipv6 Access-List
402
Deny | Permit} (Ipv6)
403
Ipv6 Access-List Rename
403
Ipv6 Traffic-Filter
404
Ipv6 Traffic-Filter
405
Mac Access-Group
405
Cos (Class of Service) Command
406
Show Commands
406
Show Queue Cos-Map
406
Show Queue Ip-Dscp-Mapping
407
Show Queue Cos-Queue
408
Show Queue Trust
408
Configuration Commands
409
Queue Cos-Map
409
Queue Trust
410
Queue Cos-Queue Min-Bandwidth
411
Queue Cos-Queue Strict
412
Queue Cos-Queue Traffic-Shape
413
7 Routing Commands
415
Address Resolution Protocol (ARP) Commands
415
Show Commands
415
Show Ip Arp
415
Show Ip Arp Brief
416
Show Ip Arp Static
416
Configuration Commands
417
Arp
417
Ip Proxy-Arp
417
Arp Cachesize
418
Ip Local-Proxy-Arp
418
Arp Dynamicrenew
419
Arp Purge
419
Arp Resptime
420
Arp Retries
420
Arp Timeout
420
Clear Ip Arp-Cache
421
IP Routing Commands
421
Show Commands
421
Show Ip Brief
421
Show Ip Interface Brief
422
Show Ip Interface Port
422
Show Ip Route
423
Show Ip Route Bestroutes
424
Show Ip Route Connected
425
Show Ip Route Entry
425
Show Ip Route Ospf
426
Show Ip Route Rip
427
Show Ip Route Static
428
Show Ip Route Summary
428
Show Ip Route Precedence
429
Show Ip Traffic
429
Configuration Commands
430
Ip Routing
430
Routing
430
Ip Address
431
Ip Route
431
Ip Route Default-Next-Hop
432
Ip Route Precedence
432
Ip Directed-Broadcast
433
Ip Forwarding
433
Ip Mtu
433
Encapsulation
434
Open Shortest Path First (OSPF) Commands
434
Show Commands
434
Show Ip Ospf
435
Show Ip Ospf Abr
436
Show Ip Ospf Area
436
Show Ip Ospf Asbr
437
Show Ip Ospf Database
437
Show Ip Ospf Database Database-Summary
438
Show Ip Ospf Interface
439
Show Ip Ospf Interface Brief
440
Show Ip Ospf Interface Stats
441
Show Ip Ospf Neighbor
441
Show Ip Ospf Neighbor Brief
444
Show Ip Ospf Range
444
Show Ip Ospf Statistics
445
Show Ip Ospf Stub Table
446
Show Ip Ospf Virtual-Link
446
Show Ip Ospf Virtual-Link Brief
447
Configuration Commands
448
Enable Ospf
448
No Area
448
1583Compatibility
449
Area Default-Cost
449
Ip Ospf
449
Area Nssa
450
Area Nssa Default-Info-Originate
450
Area Nssa No-Redistribute
451
Area Nssa No-Summary
451
Area Nssa Translator-Role
452
Area Nssa Translator-Stab-Intv
452
Area Range
453
Area Stub
454
Area Stub Summarylsa
454
Area Virtual-Link Authentication
455
Area Virtual-Link Dead-Interval
455
Area Virtual-Link Hello-Interval
456
Area Virtual-Link Retransmit-Interval
457
Area Virtual-Link Transmit-Delay
457
Default-Information Originate
458
Default-Metric
458
Distance Ospf
459
Distribute-List out
460
Exit-Overflow-Interval
460
External-Lsdb-Limit
461
Ip Ospf Areaid
461
Ip Ospf Authentication
462
Ip Ospf Cost
463
Ip Ospf Dead-Interval
463
Ip Ospf Hello -Interval
464
Ip Ospf Priority
464
Ip Ospf Retransmit-Interval
465
Ip Ospf Mtu-Ignore
466
Ip Ospf Transmit-Delay
466
Redistribute
467
Router-ID
467
Maximum-Paths
468
Timers Spf
469
Bootp/Dhcp Relay Commands
469
Show Bootpdhcprelay
469
Bootpdhcprelay Cidoptmode
470
Bootpdhcprelay Enable
470
Bootpdhcprelay Maxhopcount
470
Bootpdhcprelay Minwaittime
471
Bootpdhcprelay Serverip
471
Domain Name Server Relay Commands
472
Show Commands
472
Show Dns
472
Show Hosts
472
Show Dns Cache
473
Configuration Commands
474
Clear Hosts
474
Ip Hosts
474
Ip Domain-List
475
Ip Domain-Name
475
Ip Domain-Lookup
476
Ip Name-Server
476
Clear Dns
477
Clear Domain-List
477
Clear Dns Cache
478
Clear Dns Counter
478
Routing Information Protocol (RIP) Commands
479
Show Commands
479
Show Ip Rip
479
Show Ip Rip Interface
480
Show Ip Rip Interface Brief
481
Configuration Commands
481
Enable Rip
481
Auto-Summary
482
Ip Rip
482
Default-Information Originate
483
Default-Metric
483
Distance Rip
484
Hostrouteaccept
484
Distribute-List
485
Split-Horizon
485
Redistribute
486
Ip Rip Authentication
487
Ip Rip Receive Version
487
Ip Rip Send Version
488
Router Discovery Protocol Commands
489
Show Ip Irdp
489
Ip Irdp
489
Ip Irdp Broadcast
490
Ip Irdp Holdtime
490
Ip Irdp Maxadvertinterval
491
Ip Irdp Minadvertinterval
491
Ip Irdp Preference
492
VLAN Routing Commands
492
Show Ip Vlan
492
Vlan Routing
493
Virtual Router Redundancy Protocol (VRRP) Commands
493
Show Commands
493
Show Ip Vrrp
493
Show Ip Vrrp Brief
494
Show Ip Vrrp Interface
495
Show Ip Vrrp Interface Stats
495
Configuration Commands
496
Ip Vrrp
496
Ip Vrrp Ip
497
Ip Vrrp Authentication
498
Ip Vrrp Mode
498
Ip Vrrp Preempt
499
Ip Vrrp Priority
499
Ip Vrrp Timers Advertise
500
DHCP Filtering Commands
500
Show Commands
501
Show Ip Dhcp Filtering
501
Configuration Commands
501
Ip Dhcp Filtering
501
Ip Dhcp Filtering Trust
502
8 IP Multicast Commands
503
Distance Vector Multicast Routing Protocol (DVMRP) Commands
503
Show Commands
503
Show Ip Dvmrp
503
Show Ip Dvmrp Interface
503
Show Ip Dvmrp Neighbor
504
Show Ip Dvmrp Nexthop
505
Show Ip Dvmrp Prune
505
Show Ip Dvmrp Route
506
Configuration Commands
506
Ip Dvmrp
506
Ip Dvmrp Metric
507
Internet Group Management Protocol (IGMP) Commands
508
Show Commands
508
Show Ip Igmp
508
Show Ip Igmp Groups
509
Show Ip Igmp Interface
510
Show Ip Igmp Interface Membership
511
Show Ip Igmp Interface Stats
512
Configuration Commands
512
Ip Igmp
512
Ip Igmp Version
513
Ip Igmp Last-Member-Query-Count
514
Ip Igmp Last-Member-Query-Interval
514
Ip Igmp Query-Interval
515
Ip Igmp Query-Max-Response-Time
515
Ip Igmp Robustness
516
Ip Igmp Startup-Query-Count
516
Ip Igmp Startup-Query-Interval
517
Multicast Commands
517
Show Commands
517
Show Ip Mcast
517
Show Ip Mcast Boundary
518
Show Ip Mcast Interface
519
Show Ip Mcast Mroute
519
Show Mrinfo
522
Show Mstat
523
Show Mtrace
524
Configuration Commands
524
Ip Multicast
524
Ip Multicast Staticroute
525
No Ip Mcast Mroute
526
Ip Mcast Boundary
527
Ip Multicast Ttl-Threshold
527
Mrinfo
528
Mstat
528
Mtrace
529
Disable Ip Multicast Mdebug Mtrace
530
Protocol Independent Multicast - Dense Mode (PIM-DM) Commands
530
Show Commands
530
Show Ip Pimdm
530
Show Ip Pimdm Interface
531
Show Ip Pimdm Interface Stats
532
Show Ip Pimdm Neighbor
532
Configuration Commands
533
Ip Pimdm
533
Ip Pimdm Mode
533
Ip Pimdm Query-Interval
534
Protocol Independent Multicast - Sparse Mode (PIM-SM) Commands
534
Show Commands
535
Show Ip Pimsm
535
Show Ip Pimsm Componenttable
535
Show Ip Pimsm Interface
536
Show Ip Pimsm Interface Stats
537
Show Ip Pimsm Neighbor
537
Show Ip Pimsm Rp
538
Show Ip Pimsm Rphash
539
Show Ip Pimsm Staticrp
539
Configuration Commands
540
Ip Pimsm
540
Ip Pimsm Message-Interval
540
Ip Pimsm Register-Rate-Limit
541
Ip Pimsm Spt-Threshold
542
Ip Pimsm Staticrp
542
Ip Pimsm Mode
543
Ip Pimsm Query-Interval
543
Ip Pimsm Cbsrhashmasklength
544
Ip Pimsm Cbsrpreference
544
Ip Pimsm Crppreference
545
IGMP Proxy Commands
546
Show Commands
546
Show Ip Igmp-Proxy
546
Show Ip Igmp-Proxy Groups
547
Show Ip Igmp-Proxy Groups Detail
547
Show Ip Igmp-Proxy Interface
548
Configuration Commands
549
Ip Igmp-Proxy
549
Ip Igmp-Proxy Reset-Status
549
Ip Igmp-Proxy Unsolicit-Rprt-Interval
550
9 IPV6 Commands
551
Tunnel Interface Commands
551
Show Commands
551
Show Interface Tunnel
551
Configuration Commands
552
Interface Tunnel
552
Tunnel Source
552
Tunnel Destination
553
Tunnel Mode Ipv6Ip
553
Loopback Interface Commands
553
Show Commands
554
Show Interface Loopback
554
Configuration Commands
554
Interface Loopback
554
Ipv6 Routing Commands
555
Show Commands
555
Show Ipv6 Brief
555
Show Ipv6 Interface
556
Show Ipv6 Neighbors
557
Show Ipv6 Route
557
Show Ipv6 Route Preferences
558
Show Ipv6 Route Summary
559
Show Ipv6 Vlan
559
Show Ipv6 Traffic
560
Show Ipv6 Neighbors Static
563
Configuration Commands
563
Ipv6 Forwarding
563
Ipv6 Enable
564
Ipv6 Unicast-Routing
564
Ipv6 Address
565
Ipv6 Mtu
566
Ipv6 Route
566
Ipv6 Nd Dad Attempts
567
Ipv6 Nd Managed-Config-Flag
567
Ipv6 Nd Ns-Interval
568
Ipv6 Nd Other-Config-Flag
568
Ipv6 Nd Ra-Interval
569
Ipv6 Nd Ra-Lifetime
569
Ipv6 Nd Reachable-Time
570
Ipv6 Nd Suppress-Ra
570
Ipv6 Nd Prefix
571
Ipv6 Neighbor Static
572
Ospfv3 Commands
572
Show Commands
572
Show Ipv6 Ospf
572
Show Ip Ospf Abr
573
Show Ipv6 Ospf Area
574
Show Ipv6 Ospf Asbr
575
Show Ipv6 Ospf Database
575
Show Ipv6 Ospf Database Database-Summary
576
Show Ipv6 Ospf Interface
577
Show Ipv6 Ospf Interface Brief
578
Show Ipv6 Ospf Interface Stats
579
Show Ipv6 Ospf Neighbor
580
Show Ipv6 Ospf Range
581
Show Ipv6 Ospf Stub Table
582
Show Ipv6 Ospf Virtual-Link
583
Show Ipv6 Ospf Virtual-Link Brief
583
Configuration Commands
584
Ipv6 Ospf
584
Ipv6 Ospf Areaid
584
Ipv6 Ospf Cost
585
Ipv6 Ospf Dead-Interval
585
Ipv6 Ospf Hello-Interval
586
Ipv6 Ospf Mtu-Ignore
586
Ipv6 Ospf Network
587
Ipv6 Ospf Priority
587
Ipv6 Ospf Retransmit-Interval
588
Ipv6 Ospf Transmit-Delay
588
Area Default-Cost (Ospfv3)
589
Ipv6 Router Ospf
589
Area Nssa (Osfpv3)
590
Area Nssa Default-Info-Originate (Ospfv3)
590
Area Nssa No-Redistribute (Ospfv3)
591
Area Nssa No-Summary (Ospfv3)
591
Area Nssa Translator-Role (Ospfv3)
592
Area Nssa Translator-Stab-Intv (Ospfv3)
592
Area Range (Ospfv3)
593
Area Stub (Ospfv3)
594
Area Stub No-Summary (Ospfv3)
594
Area Virtual-Link (Ospfv3)
595
Area Virtual-Link Dead-Interval (Ospfv3)
595
Area Virtual-Link Hello-Interval (Ospfv3)
596
Area Virtual-Link Retransmit-Interval (Ospfv3)
596
Area Virtual-Link Transmit-Delay (Ospfv3)
597
Default-Information Originate (Ospfv3)
597
Default-Metric (Ospfv3)
598
Distance Ospf (Ospfv3)
598
Enable (Ospfv3)
599
Exit-Overflow-Interval (Ospfv3)
599
External-Lsdb-Limit (Ospfv3)
600
Maximum-Paths (Ospfv3)
601
Redistribute (Ospfv3)
601
Router-ID (Ospfv3)
602
Ripng Commands
602
Show Commands
602
Show Ipv6 Rip
602
Configuration Commands
603
Enable
603
Default-Information Originate
604
Ipv6 Rip
604
Default-Metric
605
Distance Rip
605
Split-Horizon
605
Redistribute
606
Ipv6 Rip Passive-Interface
607
Ipv6 Rip Timer
607
Dhcpv6 Commands
608
Show Commands
608
Show Ipv6 Dhcp
608
Show Ipv6 Dhcp Statistics
609
Show Ipv6 Dhcp Interface
610
Show Ipv6 Dhcp Pool
610
Show Ipv6 Dhcp Binding
611
Configuration Commands
612
Ipv6 Dhcp Server
612
Service Dhcpv6
612
Ipv6 Dhcp Relay Destination
613
Ipv6 Dhcp Relay-Agent-Info-Opt
613
Ipv6 Dhcp Pool
614
Ipv6 Dhcp Relay-Agent-Info-Remote-ID-Subopt
614
Dns-Server(Ipv6)
615
Domain-Name(Ipv6)
615
Prefix-Delegation (IPV6)
616
10 Network Cluster Management Commands
616
Cluster Commands
617
Show Commands
617
Show Cluster
617
Show Cluster Candidates
618
Show Cluster Members
618
Configuration Commands
619
Cluster
619
Cluster Register Timer
619
Cluster Commander
620
Cluster Member
620
Clear Cluster Candidate-Table
621
Cluster Auto-Add Enable
621
Cluster Heartbeat
622
Cluster Holdtime
622
Cluster Rcommand Member
622
Cluster Rcommand Commander
623
Cluster Reset Member
623
Cluster Update Member
624
11 Web-Based Management Interface
625
Overview
625
Main Menu
626
System Menu
626
View ARP Cache
626
Viewing Inventory Information
627
Configuring Management Session and Network Parameters
629
Defining Forwarding Database
646
Viewing Logs
647
Managing Switch Interface
653
Defining SNMP
662
Viewing Statistics
665
Managing System Utilities
676
Defining Trap Manager
686
Configuring SNTP
689
Defining DHCP Client
695
Defining Sflow Function
696
Switching Menu
698
Managing DHCP Filtering
698
Managing Filters
700
Managing Port-Based VLAN
701
Viewing Vlan Port Summary Page
705
Resetting Vlan Configuration Page Command Buttons
706
Managing Protected Ports
707
Managing Protocol-Based VLAN
709
Managing IP Subnet-Based VLAN
711
Managing MAC-Based VLAN
712
Managing MAC-Based Voice VLAN
714
Managing Voice VLAN
715
Defining GARP
716
Managing IGMP Snooping
720
Managing IGMP Snooping Querier
728
Managing MLD Snooping
732
Managing MLD Snooping Querier
739
Managing Port-Channel
743
Viewing Multicast Forwarding Database
745
Managing Spanning Tree
749
Defining 802.1P Priority
757
Managing Port Security
758
Managing LLDP
762
Managing LLDP-MED
770
Managing VTP
777
Routing Menu
779
Managing ARP Table
779
Managing IP Interfaces
782
Managing OSPF
788
Managing BOOTP/DHCP Relay Agent
809
Managing DNS Relay
811
Managing Routing Information Protocol (RIP)
815
Managing Router Discovery
821
Managing Route Table
823
Managing VLAN Routing
828
Managing VRRP
830
Managing Tunnels
835
Managing Loopbacks
837
Security Menu
839
Managing Access Control (802.1X)
839
Managing RADIUS
850
Defining TACACS+ Configuration
855
Defining IP Filter Configuration
857
Defining Secure Http Configuration
858
Defining Secure Shell Configuration
859
Ipv6 Menu
860
Configuring Ipv6 Global Configuration Page
860
Configuring Ipv6 Interface Configuration Page
861
Viewing Ipv6 Interface Summary Page
863
Viewing Ipv6 Interface Statistics Page
864
Viewing Ipv6 Neighbor Table Information Page
870
Viewing Ipv6 Static Neighbor Table Information Page
872
Managing Dhcpv6 Protocol
872
Managing Ospfv3 Protocol
879
Managing Ipv6 Routes
897
Managing Ripv6
901
QOS Menu
905
Managing Access Control Lists
905
Managing Differentiated Services
922
Configuring Diffserv Wizard Page
930
Managing Class of Service
932
IP Multicast Menu
937
Managing DVMRP Protocol
937
Managing IGMP Protocol
943
Defining Multicast Configuration
953
Configuring Multicast Mdebug
958
Managing PIM-DM Protocol
962
Managing PIM-SM Protocol
964
4
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the QUANTA LB4M and is the answer not in the manual?
Ask a question
QUANTA LB4M Specifications
General
Brand
QUANTA
Model
LB4M
Category
Switch
Language
English
Related product manuals
QUANTA QuantaMesh T3048-LY2R
44 pages
To Next PageTo Next PageTo Previous PageTo Previous Page
Loading...
Need help?
General
