Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 372/970
6.18.2.11 match ethertype
This command adds to the specified class definition a match condition based on the value of
the ethertype. The <ethertype> value is specified as one of the following keywords: appletalk,
arp, ibmsna, ipv4, ipv6, ipx, mplsmcast, mplsucast, netbios, novell, pppoe, rarp or as a
custom ethertype value in the range of 0x0600-0xFFFF.
NOTE: This command is not available on the Broadcom 5630x platform.
Syntax
match ethertype {<keyword> | <0x0600-0xFFFF>}
<keyword> - Specifies appletalk, arp, ibmsna, ipv4, ipv6, ipx, mplsmcast etc
<0x0600-0xFFFF> - Specifies ethertype value.
Default Setting
None
Command Mode
Class-Map Config
6.18.2.12 match ip dscp
This command adds to the specified class definition a match condition based on the value of
the IP DiffServ Code Point (DSCP) field in a packet, which is defined as the high-order six bits
of the Service Type octet in the IP header (the low-order two bits are not checked).
Syntax
match ip dscp <value>
<dscpval> value is specified as either an integer from 0 to 63, or symbolically through one of
the following keywords: af11, af12, af13, af21, af22, af23, af31, af32, af33, af41, af42, af43,
be, cs0, cs1, cs2, cs3, cs4, cs5, cs6, cs7, ef.
Note: The ip dscp, ip precedence, and ip tos match conditions are alternative ways to specify a
match criterion for the same Service Type field in the IP header, but with a slightly different
