UANTA COMPUTER INC.
Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 373/970
user notation.
Note: To specify a match on all DSCP values, use the match [not] ip tos <tosbits> <tosmask>
command with <tosbits> set to 0 and <tosmask> set to 03 (hex).
Default
None
Command Mode
Class-Map Config
6.18.2.13 match ip precedence
This command adds to the specified class definition a match condition based on the value of
the IP Precedence field in a packet, which is defined as the high-order three bits of the Service
Type octet in the IP header (the low-order five bits are not checked). The precedence value is
an integer from 0 to 7.
Syntax
match ip precedence <0-7>
Note: The ip dscp, ip precedence, and ip tos match conditions are alternative ways to specify a
match criterion for the same Service Type field in the IP header, but with a slightly different
user notation.
Note: To specify a match on all Precedence values, use the match [not] ip tos <tosbits>
<tosmask> command with <tosbits> set to 0 and <tosmask> set to 1F (hex).
Default
None
Command Mode
Class-Map Config
6.18.2.14 match ip tos
This command adds to the specified class definition a match condition based on the value of
the IP TOS field in a packet, which is defined as all eight bits of the Service Type octet in the IP
header.
