Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 518/970
Syntax
show ip mcast
Default Setting
None
Command Mode
Privileged Exec
Display Message
Admin Mode: This field displays the administrative status of multicast. This is a configured
value.
Protocol State: This field indicates the current state of the multicast protocol. Possible
values are Operational or Non-Operational.
Table Max Size: This field displays the maximum number of entries allowed in the multicast
table.
Number Of Packets For Which Source Not Found: This displays the number of packets
for which the source is not found.
Number Of Packets For Which Group Not Found: This displays the number of packets for
which the group is not found.
Protocol: This field displays the multicast protocol running on the router. Possible values are
PIMDM, PIMSM, or DVMRP.
Forwarding Multicast Stream Entry Count: This field displays the number of entries in the
multicast table.
Highest Entry Count: This field displays the highest entry count in the multicast table.
8.3.1.2 show ip mcast boundary
This command displays all the configured administrative scoped multicast boundaries.
Syntax
show ip mcast boundary {<slot/port> | all}
<slot/port > - Interface number.
all - This command represents all interfaces.
Default Setting
None
Command Mode
