Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 380/970
mirror <slot/port>
<slot/port> - Interface Number.
Default Setting
None
Command Mode
Policy-Class-Map Config
6.18.3.4 redirect
This command specifies that all incoming packets for the associated traffic stream are
redirected to a specific egress interface (physical port or port-channel).
Syntax
redirect <slot/port>
Command Mode
Policy-Class-Map Config
6.18.3.5 conform-color
This command is used to enable color-aware traffic policing and define the conform-color class
maps used. Used in conjunction with the police command where the fields for the conform level
(for simple, single-rate, and two-rate policing) are specified. The <class-map-name> parameter
is the name of an existing Diffserv class map, where different ones must be used for the
conform and exceed colors.
