Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 732/970
11.2.2.13 Managing MLD Snooping
11.2.2.13.1. Configuring MLD Snooping Global Configuration and Status Page
Use this menu to configure the parameters for MLD Snooping, which is used to build
forwarding lists for multicast traffic. Note that only a user with Read/Write access privileges
may change the data on this screen.
Configurable Data
Admin Mode - Select the administrative mode for MLD Snooping for the switch from the
pulldown menu. The default is disable.
Non-Configurable Data
Multicast Control Frame Count - The number of multicast control frames that are
processed by the CPU.
Interfaces Enabled for MLD Snooping - A list of all the interfaces currently enabled for
MLD Snooping.
Data Frames Forwarded by the CPU - The number of data frames forwarded by the
CPU.
VLAN Ids Enabled For MLD Snooping - Displays VLAN Ids enabled for MLD snooping.
Command Buttons
Submit - Update the switch with the values you entered. If you want the switch to retain
the new values across a power cycle you must perform a save. You will only see this
button if you have Read/Write access privileges.
