Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 647/970
MAC address.
Source Slot/Port - the port where this address was learned -- that is, the port through
which the MAC address can be reached.
ifIndex - The ifIndex of the MIB interface table entry associated with the source port.
Status - The status of this entry. The possible values are:
Static: the entry was added when a static MAC filter was defined.
Learned: the entry was learned by observing the source MAC addresses of incoming
traffic, and is currently in use.
Management: the system MAC address, which is identified with interface 0.1.
Self: the MAC address of one of the switch's physical interfaces.
Command Buttons
Search - Search for the specified MAC address.
Refresh - Refetch the database and display it again starting with the first entry in the table.
11.2.1.5 Viewing Logs
11.2.1.5.1. Viewing Buffered Log Configuration Page
This log stores messages in memory based upon the settings for message component and
severity.
Configurable Data
Admin Status - A log that is "Disabled" shall not log messages. A log that is "Enabled"
shall log messages. Enable or Disable logging by selecting the corresponding line on the
pulldown entry field.
Behavior Indicates the behavior of the log when it is full. It can either wrap around or stop
when the log space is filled.
Command Buttons
