Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 548/970
Command Mode
Privileged Exec
Display Message
Interface: The interface number of the IGMP Proxy.
Group Address: The IP address of the multicast group.
Last Reporter: The IP address of host that last sent a membership report for the current
group, on the network attached to the IGMP-Proxy interface (upstream interface).
Up Time (in secs): The time elapsed since last created.
Member State: The status of the entry. Possible values are IDLE_MEMBER or
DELAY_MEMBER.
IDLE_MEMBER - interface has responded to the latest group membership query for this
group.
DELAY_MEMBER - interface is going to send a group membership report to respond to
a group membership query for this group.
Filter Mode: Possible values are include or exclude.
Sources: The number of sources attached to the multicast group.
Group Source List: The list of IP addresses of the sources attached to the multicast group.
Expiry Time: Time left before a source is deleted.
8.6.1.4 show ip igmp-proxy interface
This command displays a detailed list of the host interface status parameters. It displays the
following parameters only when you enable IGMP Proxy.
Syntax
show ip igmp-proxy interface
Default Setting
None
Command Mode
Privileged Exec
Display Message
Interface Index: Shows the slot/port of the IGMP proxy.
The column headings of the table associated with the interface are as follows:
Ver: Shows the IGMP version.
Query Rcvd: Number of IGMP queries received.
Report Rcvd: Number of IGMP reports received.
Report Sent: Number of IGMP reports sent.
Leaves Rcvd: Number of IGMP leaves received.
Leaves Sent: Number of IGMP leaves sent.
